Specifications: Ford Focus II Hatchback 1.8 TDCi (116 Hp) 2005, 2006

2005 Ford Focus II Hatchback - Photo 1

Ford Focus II Hatchback 1.8 TDCi (116 Hp) – Full specifications
General information
Brand Ford
Model Focus
Generation Focus II Hatchback
Modification (Engine) 1.8 TDCi (116 Hp)
Start of production 2005 year
End of production 2006 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3/5
Performance specs
Fuel consumption (economy) – urban 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
Fuel consumption (economy) – extra urban 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
Fuel consumption (economy) – combined 5.2 l/100 km
45.2 US mpg
54.3 UK mpg
19.2 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.8 sec
Acceleration 0 – 62 mph 10.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.3 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 4
Weight-to-power ratio 11.7 kg/Hp, 85.5 Hp/tonne
Weight-to-torque ratio 5.4 kg/Nm, 184.2 Nm/tonne
Engine specs
Power 116 Hp @ 3800 rpm.
Power per litre 66.2 Hp/l
Torque 250 Nm @ 2000 rpm.
184.39 lb.-ft. @ 2000 rpm.
Engine layout Front, Transverse
Engine Model/Code BHPA
Engine displacement 1753 cm3
106.97 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 18.5:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain OHC
Engine oil capacity 5.6 l
5.92 US qt | 4.93 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.1 l
8.56 US qt | 7.13 UK qt

Space, Volume and weights
Kerb Weight 1357 kg
2991.67 lbs.
Max. weight 1775 kg
3913.21 lbs.
Max load 418 kg
921.53 lbs.
Trunk (boot) space – minimum 385 l
13.6 cu. ft.
Trunk (boot) space – maximum 1247 l
44.04 cu. ft.
Fuel tank capacity 53 l
14 US gal | 11.66 UK gal
Dimensions
Length 4342 mm
170.94 in.
Width 1840 mm
72.44 in.
Height 1497 mm
58.94 in.
Wheelbase 2640 mm
103.94 in.
Front track 1535 mm
60.43 in.
Rear (Back) track 1531 mm
60.28 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 195/65 R15
Wheel rims size 6J x 15
