Specifications: Ford Focus III Hatchback (facelift 2014) 1.6 TDCi (95 Hp) S&S 2014, 2015

2014 Ford Focus III Hatchback (facelift 2014) - Photo 1

Ford Focus III Hatchback (facelift 2014) 1.6 TDCi (95 Hp) S&S – Full specifications
General information
Brand Ford
Model Focus
Generation Focus III Hatchback (facelift 2014)
Modification (Engine) 1.6 TDCi (95 Hp) S&S
Start of production 2014 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
Fuel consumption (economy) – extra urban 3.7 l/100 km
63.6 US mpg
76.3 UK mpg
27 km/l
Fuel consumption (economy) – combined 4.2 l/100 km
56 US mpg
67.3 UK mpg
23.8 km/l
CO2 emissions 109 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.5 sec
Acceleration 0 – 62 mph 12.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.9 sec
Maximum speed 182 km/h
113.09 mph
Emission standard Euro 6
Weight-to-power ratio 14 kg/Hp, 71.3 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 161.4 Nm/tonne
Engine specs
Power 95 Hp @ 3800 rpm.
Power per litre 60.9 Hp/l
Torque 215 Nm @ 1750 rpm.
158.58 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code TZJA, T3DA, T3DB
Engine displacement 1560 cm3
95.2 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 88.3 mm
3.48 in.
Compression ratio 16:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 3.85 l
4.07 US qt | 3.39 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.3 l
7.71 US qt | 6.42 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1332 kg
2936.56 lbs.
Max. weight 1900 kg
4188.78 lbs.
Max load 568 kg
1252.23 lbs.
Trunk (boot) space – minimum 277 l
9.78 cu. ft.
Trunk (boot) space – maximum 1062 l
37.5 cu. ft.
Fuel tank capacity 53 l
14 US gal | 11.66 UK gal
Dimensions
Length 4358 mm
171.57 in.
Width 1823 mm
71.77 in.
Height 1484 mm
58.43 in.
Wheelbase 2648 mm
104.25 in.
Front track 1544 mm
60.79 in.
Rear (Back) track 1559 mm
61.38 in.
Minimum turning circle (turning diameter) 11 m
36.09 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16; 215/50 R17
Wheel rims size 6.5J x 16; 7.0J x 17
