Specifications: Ford Fusion I (facelift 2005) 1.4 (80 Hp) 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012

2005 Ford Fusion I (facelift 2005) - Photo 1

Ford Fusion I (facelift 2005) 1.4 (80 Hp) – Full specifications
General information
Brand Ford
Model Fusion
Generation Fusion I (facelift 2005)
Modification (Engine) 1.4 (80 Hp)
Start of production 2005 year
End of production 2012 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 8.5 l/100 km
27.7 US mpg
33.2 UK mpg
11.8 km/l
Fuel consumption (economy) – extra urban 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
Fuel consumption (economy) – combined 6.5 l/100 km
36.2 US mpg
43.5 UK mpg
15.4 km/l
CO2 emissions 154 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 14 sec
Acceleration 0 – 62 mph 14 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 13.3 sec
Maximum speed 163 km/h
101.28 mph
Emission standard Euro 4
Weight-to-power ratio 13.6 kg/Hp, 73.7 Hp/tonne
Weight-to-torque ratio 8.8 kg/Nm, 114.3 Nm/tonne
Engine specs
Power 80 Hp @ 5700 rpm.
Power per litre 57.6 Hp/l
Torque 124 Nm @ 3500 rpm.
91.46 lb.-ft. @ 3500 rpm.
Engine layout Front, Transverse
Engine Model/Code FXJA, FXJB, FXJC
Engine displacement 1388 cm3
84.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 76 mm
2.99 in.
Piston Stroke 76.5 mm
3.01 in.
Compression ratio 11:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5 l
5.28 US qt | 4.4 UK qt

Space, Volume and weights
Kerb Weight 1085 kg
2392.02 lbs.
Max. weight 1605 kg
3538.42 lbs.
Max load 520 kg
1146.4 lbs.
Trunk (boot) space – minimum 337 l
11.9 cu. ft.
Trunk (boot) space – maximum 1175 l
41.49 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Permitted trailer load with brakes (12%) 900 kg
1984.16 lbs.
Permitted trailer load without brakes 500 kg
1102.31 lbs.
Dimensions
Length 4013 mm
157.99 in.
Width 1724 mm
67.87 in.
Height 1543 mm
60.75 in.
Wheelbase 2486 mm
97.87 in.
Front track 1487 mm
58.54 in.
Rear (Back) track 1445 mm
56.89 in.
Ride height (ground clearance) 160 mm
6.3 in.
Drag coefficient (Cd) 0.35
Minimum turning circle (turning diameter) 10.3 m
33.79 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Drum
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/55 R16
Wheel rims size 16
