Specifications: Ford Galaxy III 2.0 TDCi (210 Hp) Powershift S&S 2015, 2016, 2017, 2018

2015 Ford Galaxy III - Photo 1

Ford Galaxy III 2.0 TDCi (210 Hp) Powershift S&S – Full specifications
General information
Brand Ford
Model Galaxy
Generation Galaxy III
Modification (Engine) 2.0 TDCi (210 Hp) Powershift S&S
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – extra urban 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
Fuel consumption (economy) – combined 5.5 l/100 km
42.8 US mpg
51.4 UK mpg
18.2 km/l
CO2 emissions 144 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.9 sec
Acceleration 0 – 62 mph 8.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.5 sec
Maximum speed 214 km/h
132.97 mph
Emission standard Euro 6
Weight-to-power ratio 8.1 kg/Hp, 123.2 Hp/tonne
Weight-to-torque ratio 3.8 kg/Nm, 264.1 Nm/tonne
Engine specs
Power 210 Hp @ 3750 rpm.
Power per litre 105.2 Hp/l
Torque 450 Nm @ 2000-2250 rpm.
331.9 lb.-ft. @ 2000-2250 rpm.
Engine layout Front, Transverse
Engine Model/Code T9CB, T9CC, T9CD
Engine displacement 1997 cm3
121.86 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 85 mm
3.35 in.
Piston Stroke 88 mm
3.46 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration BiTurbo, Intercooler
Valvetrain DOHC
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.2 l
8.66 US qt | 7.21 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1704 kg
3756.68 lbs.
Max. weight 2620 kg
5776.11 lbs.
Max load 916 kg
2019.43 lbs.
Trunk (boot) space – minimum 300 l
10.59 cu. ft.
Trunk (boot) space – maximum 2339 l
82.6 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4848 mm
190.87 in.
Width 1916 mm
75.43 in.
Width with mirrors folded 1953 mm
76.89 in.
Width including mirrors 2137 mm
84.13 in.
Height 1747 mm
68.78 in.
Wheelbase 2849 mm
112.17 in.
Front track 1606 mm
63.23 in.
Rear (Back) track 1606 mm
63.23 in.
Ride height (ground clearance) 124 mm
4.88 in.
Minimum turning circle (turning diameter) 12 m
39.37 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission Powershift
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 235/55 R17; 235/50 R18; 245/45 R19
Wheel rims size 7.5J x 17; 7.5J x 18; 8J x 19
