Specifications: Ford Kuga III 2.0 EcoBlue (150 Hp) Mild Hybrid 2020, 2021

2020 Ford Kuga III - Photo 1

Ford Kuga III 2.0 EcoBlue (150 Hp) Mild Hybrid – Full specifications
General information
Brand Ford
Model Kuga
Generation Kuga III
Modification (Engine) 2.0 EcoBlue (150 Hp) Mild Hybrid
Start of production September, 2020 year
End of production November, 2021 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type SUV
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 5.0-5.1 l/100 km
47 – 46.1 US mpg
56.5 – 55.4 UK mpg
20 – 19.6 km/l
CO2 emissions (WLTP) 132-135 g/km
Fuel consumption (economy) – urban (NEDC) 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
Fuel consumption (economy) – extra urban (NEDC) 4.0-4.1 l/100 km
58.8 – 57.4 US mpg
70.6 – 68.9 UK mpg
25 – 24.4 km/l
Fuel consumption (economy) – combined (NEDC) 4.3-4.4 l/100 km
54.7 – 53.5 US mpg
65.7 – 64.2 UK mpg
23.3 – 22.7 km/l
CO2 emissions (NEDC) 111-113 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.6 sec
Acceleration 0 – 62 mph 9.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.1 sec
Maximum speed 194 km/h
120.55 mph
Emission standard Euro 6d-TEMP
Weight-to-power ratio 10.7 kg/Hp, 93.5 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 230.5 Nm/tonne
Engine specs
Power 150 Hp @ 3500 rpm.
Power per litre 75.2 Hp/l
Torque 370 Nm @ 2000-2500 rpm.
272.9 lb.-ft. @ 2000-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code YLDC
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 15.8:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.37 l
6.73 US qt | 5.6 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1605 kg
3538.42 lbs.
Max. weight 2155 kg
4750.96 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 435 l
15.36 cu. ft.
Trunk (boot) space – maximum 1534 l
54.17 cu. ft.
Fuel tank capacity 54 l
14.27 US gal | 11.88 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1900 kg
4188.78 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4614-4629 mm
181.65 – 182.24 in.
Width 1883 mm
74.13 in.
Width with mirrors folded 2000 mm
78.74 in.
Width including mirrors 2178 mm
85.75 in.
Height 1666-1680 mm
65.59 – 66.14 in.
Wheelbase 2710 mm
106.69 in.
Front track 1597 mm
62.87 in.
Rear (Back) track 1588 mm
62.52 in.
Ride height (ground clearance) 146-191 mm
5.75 – 7.52 in.
Minimum turning circle (turning diameter) 11.38 m
37.34 ft.
Approach angle 19.1°
Departure angle 23.6°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Ventilated discs, 308-330 mm
Rear brakes Disc, 302 mm
Assisting systems ABS (Anti-lock braking system)
Tires size 225/65 R17; 225/60 R18; 225/55 R19; 245/45 R20
Wheel rims size 7J x 17; 7.5J x 18; 7.5J x 19; 7.5J x 20; 8.0J x 20
