Specifications: Ford Mondeo III Sedan 1.8 TDCi (125 Hp) 2007, 2008, 2009, 2010

2007 Ford Mondeo III Sedan - Photo 1

Ford Mondeo III Sedan 1.8 TDCi (125 Hp) – Full specifications
General information
Brand Ford
Model Mondeo
Generation Mondeo III Sedan
Modification (Engine) 1.8 TDCi (125 Hp)
Start of production 2007 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 7.5 l/100 km
31.4 US mpg
37.7 UK mpg
13.3 km/l
Fuel consumption (economy) – extra urban 4.8 l/100 km
49 US mpg
58.9 UK mpg
20.8 km/l
Fuel consumption (economy) – combined 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.2 sec
Acceleration 0 – 62 mph 10.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.7 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 4
Weight-to-power ratio 12 kg/Hp, 83.2 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 226.2 Nm/tonne
Engine specs
Power 125 Hp @ 3850 rpm.
Power per litre 71.3 Hp/l
Torque 340 Nm @ 1750 rpm.
250.77 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code QYBA
Engine displacement 1753 cm3
106.97 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 82 mm
3.23 in.
Compression ratio 18:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.6 l
5.92 US qt | 4.93 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.9 l
8.35 US qt | 6.95 UK qt

Space, Volume and weights
Kerb Weight 1503 kg
3313.55 lbs.
Max. weight 2190 kg
4828.12 lbs.
Max load 687 kg
1514.58 lbs.
Trunk (boot) space – minimum 550 l
19.42 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4844 mm
190.71 in.
Width 1886 mm
74.25 in.
Height 1500 mm
59.06 in.
Wheelbase 2850 mm
112.2 in.
Front track 1522 mm
59.92 in.
Rear (Back) track 1537 mm
60.51 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Coil spring
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
