Specifications: Ford Mondeo III Sedan 2.5 i 20V (220 Hp) 2006, 2007, 2008, 2009, 2010

2007 Ford Mondeo III Sedan - Photo 1

Ford Mondeo III Sedan 2.5 i 20V (220 Hp) – Full specifications
General information
Brand Ford
Model Mondeo
Generation Mondeo III Sedan
Modification (Engine) 2.5 i 20V (220 Hp)
Start of production 2006 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 13.6 l/100 km
17.3 US mpg
20.8 UK mpg
7.4 km/l
Fuel consumption (economy) – extra urban 6.8 l/100 km
34.6 US mpg
41.5 UK mpg
14.7 km/l
Fuel consumption (economy) – combined 9.3 l/100 km
25.3 US mpg
30.4 UK mpg
10.8 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.5 sec
Acceleration 0 – 62 mph 7.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.1 sec
Maximum speed 245 km/h
152.24 mph
Emission standard Euro 4
Weight-to-power ratio 6.8 kg/Hp, 147.5 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 214.5 Nm/tonne
Engine specs
Power 220 Hp @ 5000 rpm.
Power per litre 87.2 Hp/l
Torque 320 Nm @ 1500-4800 rpm.
236.02 lb.-ft. @ 1500-4800 rpm.
Engine layout Front, Transverse
Engine Model/Code HUBA
Engine displacement 2522 cm3
153.9 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 93.2 mm
3.67 in.
Compression ratio 9:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.4 l
6.76 US qt | 5.63 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.1 l
7.5 US qt | 6.25 UK qt

Space, Volume and weights
Kerb Weight 1492 kg
3289.3 lbs.
Max. weight 2185 kg
4817.1 lbs.
Max load 693 kg
1527.8 lbs.
Trunk (boot) space – minimum 550 l
19.42 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4844 mm
190.71 in.
Width 1886 mm
74.25 in.
Height 1500 mm
59.06 in.
Wheelbase 2850 mm
112.2 in.
Front track 1522 mm
59.92 in.
Rear (Back) track 1537 mm
60.51 in.
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Coil spring
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
