| General information | |
|---|---|
| Brand | Ford |
| Model | Mustang |
| Generation | Mustang Convertible I (facelift 1970) |
| Modification (Engine) | 4.1 (145 Hp) |
| Start of production | 1970 year |
| End of production | 1973 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 10 kg/Hp, 99.6 Hp/tonne |
| Weight-to-torque ratio | 4.6 kg/Nm, 216.3 Nm/tonne |
| Engine specs | |
| Power | 145 Hp @ 4000 rpm. |
| Power per litre | 35.4 Hp/l |
| Torque | 315 Nm @ 2600 rpm. 232.33 lb.-ft. @ 2600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine displacement | 4097 cm3 250.01 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | Inline |
| Cylinder Bore | 93.47 mm 3.68 in. |
| Piston Stroke | 99.31 mm 3.91 in. |
| Compression ratio | 9:1 |
| Number of valves per cylinder | 2 |
| Fuel injection system | Carburettor |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | OHV |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 9 l 9.51 US qt | 7.92 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1456 kg 3209.93 lbs. |
| Trunk (boot) space – maximum | 229 l 8.09 cu. ft. |
| Fuel tank capacity | 76 l 20.08 US gal | 16.72 UK gal |
| Dimensions | |
| Length | 4813 mm 189.49 in. |
| Width | 1882 mm 74.09 in. |
| Height | 1283 mm 50.51 in. |
| Wheelbase | 2769 mm 109.02 in. |
| Front track | 1562 mm 61.5 in. |
| Rear (Back) track | 1549 mm 60.98 in. |
| Minimum turning circle (turning diameter) | 12.1 m 39.7 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 3 gears, manual transmission |
| Front suspension | Wishbone, Transverse stabilizer |
| Rear suspension | Rigid axle suspension, Leaf spring |
| Front brakes | Disc |
| Rear brakes | Drum |
| Steering type | Cone worm with recirculation balls |
| Power steering | Hydraulic Steering |
| Tires size | Front wheel tires: 185/75 R14 Rear wheel tires: 185/75 R14 |
| Wheel rims size | Front wheel rims: 6J x 14 Rear wheel rims: 6J x 14 |
