Specifications: Ford Mustang Convertible V (facelift 2009) 4.0 V6 (210 Hp) Automatic 2009, 2010

2010 Ford Mustang Convertible V (facelift 2009) - Photo 1

Ford Mustang Convertible V (facelift 2009) 4.0 V6 (210 Hp) Automatic – Full specifications
General information
Brand Ford
Model Mustang
Generation Mustang Convertible V (facelift 2009)
Modification (Engine) 4.0 V6 (210 Hp) Automatic
Start of production 2009 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 14.7 l/100 km
16 US mpg
19.2 UK mpg
6.8 km/l
Fuel consumption (economy) – extra urban 9.8 l/100 km
24 US mpg
28.8 UK mpg
10.2 km/l
Fuel Type Petrol (Gasoline)
Engine specs
Power 210 Hp @ 5300 rpm.
Power per litre 52.4 Hp/l
Torque 325 Nm @ 3500 rpm.
239.71 lb.-ft. @ 3500 rpm.
Maximum engine speed 6100 rpm.
Engine layout Front, Longitudinal
Engine Model/Code Cologne
Engine displacement 4009 cm3
244.64 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 100.4 mm
3.95 in.
Piston Stroke 84.4 mm
3.32 in.
Compression ratio 9.7:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.8 l
12.47 US qt | 10.38 UK qt

Space, Volume and weights
Trunk (boot) space – minimum 272 l
9.61 cu. ft.
Fuel tank capacity 61 l
16.11 US gal | 13.42 UK gal
Permitted trailer load with brakes (12%) 454 kg
1000.9 lbs.
Dimensions
Length 4778 mm
188.11 in.
Width 1877 mm
73.9 in.
Width including mirrors 2035 mm
80.12 in.
Height 1425 mm
56.1 in.
Wheelbase 2720 mm
107.09 in.
Front track 1582 mm
62.28 in.
Rear (Back) track 1598 mm
62.91 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Independent type McPherson, Transverse stabilizer
Rear suspension Rigid axle suspension, Transverse stabilizer, Coil spring
Front brakes Ventilated discs, 293×30 mm
Rear brakes Ventilated discs, 300×19 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/60 R17; 235/50 R18
Wheel rims size 7J x 17; 8J x 18
