Specifications: Ford Puma 1.5 EcoBlue (120 Hp) 2020, 2021

2020 Ford Puma - Photo 1

Ford Puma 1.5 EcoBlue (120 Hp) – Full specifications
General information
Brand Ford
Model Puma
Generation Puma
Modification (Engine) 1.5 EcoBlue (120 Hp)
Start of production June, 2020 year
End of production December, 2021 year
Powertrain Architecture Internal Combustion engine
Body type SUV, Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 5.2-5.7 l/100 km
45.2 – 41.3 US mpg
54.3 – 49.6 UK mpg
19.2 – 17.5 km/l
Fuel consumption at Medium speed (WLTP) 4.3-4.8 l/100 km
54.7 – 49 US mpg
65.7 – 58.9 UK mpg
23.3 – 20.8 km/l
Fuel consumption at high speed (WLTP) 3.8-4.4 l/100 km
61.9 – 53.5 US mpg
74.3 – 64.2 UK mpg
26.3 – 22.7 km/l
Fuel consumption at very high speed (WLTP) 4.9-5.5 l/100 km
48 – 42.8 US mpg
57.6 – 51.4 UK mpg
20.4 – 18.2 km/l
Combined fuel consumption (WLTP) 4.5-5 l/100 km
52.3 – 47 US mpg
62.8 – 56.5 UK mpg
22.2 – 20 km/l
CO2 emissions (WLTP) 117-132 g/km
Fuel consumption (economy) – urban (NEDC) 4.3 l/100 km
54.7 US mpg
65.7 UK mpg
23.3 km/l
Fuel consumption (economy) – extra urban (NEDC) 3.5 l/100 km
67.2 US mpg
80.7 UK mpg
28.6 km/l
Fuel consumption (economy) – combined (NEDC) 3.8 l/100 km
61.9 US mpg
74.3 UK mpg
26.3 km/l
CO2 emissions (NEDC) 99 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.3 sec
Acceleration 0 – 62 mph 10.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.8 sec
Maximum speed 185 km/h
114.95 mph
Emission standard Euro 6d
Weight-to-power ratio 10.6 kg/Hp, 94.3 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 223.9 Nm/tonne
Engine specs
Power 120 Hp @ 4000 rpm.
Power per litre 80.1 Hp/l
Torque 285 Nm @ 1750-2500 rpm.
210.21 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code ZTDA
Engine displacement 1499 cm3
91.47 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 84.8 mm
3.34 in.
Compression ratio 16.4:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.2 l
6.55 US qt | 5.46 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.3 l
7.71 US qt | 6.42 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1273 kg
2806.48 lbs.
Max. weight 1845 kg
4067.53 lbs.
Max load 572 kg
1261.04 lbs.
Trunk (boot) space – minimum 456 l
16.1 cu. ft.
Trunk (boot) space – maximum 1216 l
42.94 cu. ft.
Fuel tank capacity 40 l
10.57 US gal | 8.8 UK gal
Max. roof load 50 kg
110.23 lbs.
Permitted trailer load with brakes (8%) 1100 kg
2425.08 lbs.
Permitted trailer load with brakes (12%) 1100 kg
2425.08 lbs.
Permitted trailer load without brakes 670 kg
1477.1 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4186 mm
164.8 in.
Width 1805 mm
71.06 in.
Width including mirrors 1930 mm
75.98 in.
Height 1550 mm
61.02 in.
Wheelbase 2588 mm
101.89 in.
Front track 1567 mm
61.69 in.
Rear (Back) track 1526 mm
60.08 in.
Front overhang 850 mm
33.46 in.
Rear overhang 748 mm
29.45 in.
Ride height (ground clearance) 166 mm
6.54 in.
Minimum turning circle (turning diameter) 10.4 m
34.12 ft.
Approach angle 17.5°
Departure angle 26.6°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring, Elastic beam
Front brakes Ventilated discs, 278×25 mm
Rear brakes Disc, 271×11 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/55 R17; 215/50 R18
Wheel rims size 7J x 17; 7J x 18
