Specifications: Ford Ranger I Super Cab 2.5 TDCi (109 Hp) Automatic 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006

1998 Ford Ranger I Super Cab - Photo 1

Ford Ranger I Super Cab 2.5 TDCi (109 Hp) Automatic – Full specifications
General information
Brand Ford
Model Ranger
Generation Ranger I Super Cab
Modification (Engine) 2.5 TDCi (109 Hp) Automatic
Start of production 1998 year
End of production 2006 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 4
Doors 2
Performance specs
Fuel Type Diesel
Engine specs
Power 109 Hp @ 3500 rpm.
Power per litre 43.6 Hp/l
Torque 266 Nm @ 2000 rpm.
196.19 lb.-ft. @ 2000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code WL-T
Engine displacement 2499 cm3
152.5 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 93 mm
3.66 in.
Piston Stroke 92 mm
3.62 in.
Number of valves per cylinder 3
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6.3 l
6.66 US qt | 5.54 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.4 l
9.93 US qt | 8.27 UK qt

Space, Volume and weights
Max. weight 2087 kg
4601.05 lbs.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4998 mm
196.77 in.
Width 1695 mm
66.73 in.
Height 1740 mm
68.5 in.
Wheelbase 3000 mm
118.11 in.
Front track 1450 mm
57.09 in.
Rear (Back) track 1440 mm
56.69 in.
Ride height (ground clearance) 200 mm
7.87 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Independent torsion bar, double wishbone
Rear suspension Dependent suspension of two longitudinal semi-elliptic leaf springs
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 235/75 R15
Wheel rims size 15
