Specifications: Ford Ranger II Super Cab 2.5 TDCi (143 Hp) Automatic 2006, 2007, 2008, 2009, 2010

2006 Ford Ranger II Super Cab - Photo 1

Ford Ranger II Super Cab 2.5 TDCi (143 Hp) Automatic – Full specifications
General information
Brand Ford
Model Ranger
Generation Ranger II Super Cab
Modification (Engine) 2.5 TDCi (143 Hp) Automatic
Start of production 2006 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 10.9 l/100 km
21.6 US mpg
25.9 UK mpg
9.2 km/l
Fuel consumption (economy) – extra urban 7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l
Fuel consumption (economy) – combined 8.9 l/100 km
26.4 US mpg
31.7 UK mpg
11.2 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.5 sec
Acceleration 0 – 62 mph 12.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.9 sec
Maximum speed 147 km/h
91.34 mph
Emission standard Euro 4
Weight-to-power ratio 12.9 kg/Hp, 77.5 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 178.9 Nm/tonne
Engine specs
Power 143 Hp @ 3500 rpm.
Power per litre 57.2 Hp/l
Torque 330 Nm @ 1800 rpm.
243.4 lb.-ft. @ 1800 rpm.
Engine layout Front, Longitudinal
Engine Model/Code WLAA
Engine displacement 2499 cm3
152.5 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 93 mm
3.66 in.
Piston Stroke 92 mm
3.62 in.
Compression ratio 17.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 7 l
7.4 US qt | 6.16 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.4 l
9.93 US qt | 8.27 UK qt

Space, Volume and weights
Kerb Weight 1845 kg
4067.53 lbs.
Max. weight 3070 kg
6768.19 lbs.
Max load 1225 kg
2700.66 lbs.
Trunk (boot) space – minimum 1500 l
52.97 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 5075 mm
199.8 in.
Width 1805 mm
71.06 in.
Height 1745 mm
68.7 in.
Wheelbase 3000 mm
118.11 in.
Front track 1488 mm
58.58 in.
Rear (Back) track 1455 mm
57.28 in.
Ride height (ground clearance) 203 mm
7.99 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Independent torsion bar, double wishbone
Rear suspension Dependent suspension of two longitudinal semi-elliptic leaf springs
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 235/75 R15; 245/70 R16
Wheel rims size 15; 16
