Specifications: Ford Ranger III Double Cab 3.2 TDCi (200 Hp) 4×4 2011, 2012, 2013, 2014, 2015

2012 Ford Ranger III Double Cab - Photo 1

Ford Ranger III Double Cab 3.2 TDCi (200 Hp) 4×4 – Full specifications
General information
Brand Ford
Model Ranger
Generation Ranger III Double Cab
Modification (Engine) 3.2 TDCi (200 Hp) 4×4
Start of production 2011 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 12 l/100 km
19.6 US mpg
23.5 UK mpg
8.3 km/l
Fuel consumption (economy) – extra urban 8.1 l/100 km
29 US mpg
34.9 UK mpg
12.3 km/l
Fuel consumption (economy) – combined 9.5 l/100 km
24.8 US mpg
29.7 UK mpg
10.5 km/l
CO2 emissions 249 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.3 sec
Acceleration 0 – 62 mph 10.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.8 sec
Maximum speed 175 km/h
108.74 mph
Emission standard Euro 4
Weight-to-power ratio 10.4 kg/Hp, 96.5 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 226.7 Nm/tonne
Engine specs
Power 200 Hp @ 3000 rpm.
Power per litre 62.5 Hp/l
Torque 470 Nm @ 1500-2750 rpm.
346.65 lb.-ft. @ 1500-2750 rpm.
Engine layout Front, Longitudinal
Engine displacement 3198 cm3
195.15 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 89.9 mm
3.54 in.
Piston Stroke 100.8 mm
3.97 in.
Compression ratio 15.7:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 9.75 l
10.3 US qt | 8.58 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12.9 l
13.63 US qt | 11.35 UK qt

Space, Volume and weights
Kerb Weight 2073 kg
4570.18 lbs.
Max. weight 3200 kg
7054.79 lbs.
Max load 1127 kg
2484.61 lbs.
Trunk (boot) space – minimum 1210 l
42.73 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 5359 mm
210.98 in.
Width 1850 mm
72.83 in.
Height 1815 mm
71.46 in.
Wheelbase 3220 mm
126.77 in.
Front track 1560 mm
61.42 in.
Rear (Back) track 1560 mm
61.42 in.
Ride height (ground clearance) 229 mm
9.02 in.
Drag coefficient (Cd) 0.40
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent coil spring
Rear suspension Dependent suspension of two longitudinal semi-elliptic leaf springs
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 255/70 R16; 255/55 R16; 265/65 R17; 265/60 R18
Wheel rims size 16; 17; 18
