Specifications: Ford Ranger III Super Cab (facelift 2019) 2.0 EcoBlue (170 Hp) 4×4 2019, 2020, 2021, 2022

Ford Ranger III Super Cab (facelift 2019) 2.0 EcoBlue (170 Hp) 4×4 – Full specifications
General information
Brand Ford
Model Ranger
Generation Ranger III Super Cab (facelift 2019)
Modification (Engine) 2.0 EcoBlue (170 Hp) 4×4
Start of production January, 2019 year
End of production 2022 year
Powertrain Architecture Internal Combustion engine
Body type Pick-up
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – combined 6.9-7.2 l/100 km
34.1 – 32.7 US mpg
40.9 – 39.2 UK mpg
14.5 – 13.9 km/l
CO2 emissions 179-188 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11.1 sec
Acceleration 0 – 62 mph 11.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 180 km/h
111.85 mph
Emission standard Euro 6d-TEMP
Weight-to-power ratio 12.2 kg/Hp, 82 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 202.6 Nm/tonne
Engine specs
Power 170 Hp
Power per litre 85.1 Hp/l
Torque 420 Nm
309.78 lb.-ft.
Engine displacement 1997 cm3
121.86 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 8.1 l
8.56 US qt | 7.13 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10.6 l
11.2 US qt | 9.33 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2073-2128 kg
4570.18 – 4691.44 lbs.
Max. weight 3270 kg
7209.12 lbs.
Max load 1142-1197 kg
2517.68 – 2638.93 lbs.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
AdBlue tank 20 l
5.28 US gal | 4.4 UK gal
Permitted trailer load with brakes (12%) 3500 kg
7716.18 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 5282-5359 mm
207.95 – 210.98 in.
Width 1867 mm
73.5 in.
Width with mirrors folded 1977 mm
77.83 in.
Width including mirrors 2163 mm
85.16 in.
Height 1804-1810 mm
71.02 – 71.26 in.
Wheelbase 3220 mm
126.77 in.
Front track 1560 mm
61.42 in.
Rear (Back) track 1560 mm
61.42 in.
Ride height (ground clearance) 232-237 mm
9.13 – 9.33 in.
Minimum turning circle (turning diameter) 12.7 m
41.67 ft.
Approach angle 28.0-29.0°
Departure angle 27.0°
Ramp-over (brakeover) angle 24.0-25.0°
Climb angle 35.0°
Wading depth 800 mm
31.5 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Tires size 255/70 R16; 265/65 R17
Wheel rims size 7J x 16; 8J x 17
