Specifications: Ford S-MAX II 2.0 TDCi (180 Hp) PowerShift S&S 2015, 2016, 2017, 2018

2016 Ford S-MAX II - Photo 1

Ford S-MAX II 2.0 TDCi (180 Hp) PowerShift S&S – Full specifications
General information
Brand Ford
Model S-MAX
Generation S-MAX II
Modification (Engine) 2.0 TDCi (180 Hp) PowerShift S&S
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – extra urban 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel consumption (economy) – combined 5.4 l/100 km
43.6 US mpg
52.3 UK mpg
18.5 km/l
CO2 emissions 139 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.5 sec
Acceleration 0 – 62 mph 9.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9 sec
Maximum speed 208 km/h
129.25 mph
Emission standard Euro 6
Weight-to-power ratio 9.6 kg/Hp, 103.8 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 230.7 Nm/tonne
Engine specs
Power 180 Hp @ 3500 rpm.
Power per litre 90.1 Hp/l
Torque 400 Nm @ 2000-2500 rpm.
295.02 lb.-ft. @ 2000-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code T8CG, T8CH, T8CI, T8CJ
Engine displacement 1997 cm3
121.86 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 85 mm
3.35 in.
Piston Stroke 88 mm
3.46 in.
Compression ratio 17:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.6 l
5.92 US qt | 4.93 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.2 l
8.66 US qt | 7.21 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1734 kg
3822.82 lbs.
Max. weight 2540 kg
5599.74 lbs.
Max load 806 kg
1776.93 lbs.
Trunk (boot) space – minimum 700 l
24.72 cu. ft.
Trunk (boot) space – maximum 2200 l
77.69 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4796 mm
188.82 in.
Width 1916 mm
75.43 in.
Width including mirrors 2137 mm
84.13 in.
Height 1655 mm
65.16 in.
Wheelbase 2849 mm
112.17 in.
Front track 1606 mm
63.23 in.
Rear (Back) track 1606 mm
63.23 in.
Ride height (ground clearance) 128-150 mm
5.04 – 5.91 in.
Minimum turning circle (turning diameter) 12 m
39.37 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission PowerShift
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 235/55 R17; 235/50 R18; 245/45 R19
Wheel rims size 7.5J x 17; 7.5J x 18; 8J x 19
