Specifications: Ford Shelby I Cabrio Cobra GT 350 5.0 V8 (340 Hp) 1968, 1969, 1970

Ford Shelby I Cabrio Cobra GT 350 5.0 V8 (340 Hp) – Full specifications
General information
Brand	Ford
Model	Shelby
Generation	Shelby I Cabrio
Modification (Engine)	Cobra GT 350 5.0 V8 (340 Hp)
Start of production	1968 year
End of production	1970 year
Powertrain Architecture	Internal Combustion engine
Body type	Cabriolet
Seats	4
Doors	2
Performance specs
Fuel Type	Petrol (Gasoline)
Weight-to-power ratio	4.5 kg/Hp, 220.1 Hp/tonne
Weight-to-torque ratio	3.5 kg/Nm, 284.8 Nm/tonne
Engine specs
Power	340 Hp @ 5200 rpm.
Power per litre	68.8 Hp/l
Torque	440 Nm @ 3200 rpm. 324.53 lb.-ft. @ 3200 rpm.
Engine layout	Front, Longitudinal
Engine displacement	4942 cm³ 301.58 cu. in.
Number of cylinders	8
Engine configuration	V-engine
Cylinder Bore	101.6 mm 4 in.
Piston Stroke	76.2 mm 3 in.
Compression ratio	10.5:1
Number of valves per cylinder	2
Fuel injection system	Carburettor
Engine aspiration	Supercharger

Space, Volume and weights
Kerb Weight	1545 kg 3406.14 lbs.
Fuel tank capacity	64 l 16.91 US gal \| 14.08 UK gal
Dimensions
Length	4740 mm 186.61 in.
Width	1801 mm 70.91 in.
Height	1306 mm 51.42 in.
Wheelbase	2743 mm 107.99 in.
Front track	1476 mm 58.11 in.
Rear (Back) track	1476 mm 58.11 in.
Minimum turning circle (turning diameter)	11.6 m 38.06 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel	Rear wheel drive
Number of gears and type of gearbox	4 gears, manual transmission
Front brakes	Disc
Rear brakes	Drum
