Specifications: Ford Transit Connect II Wagon L2 1.6 TDCi (95 Hp) Start-Stop 2013, 2014, 2015, 2016

2014 Ford Transit Connect II Wagon L2 - Photo 1

Ford Transit Connect II Wagon L2 1.6 TDCi (95 Hp) Start-Stop – Full specifications
General information
Brand Ford
Model Transit Connect
Generation Transit Connect II Wagon L2
Modification (Engine) 1.6 TDCi (95 Hp) Start-Stop
Start of production 2013 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5-7
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 4.6-5 l/100 km
51.1 – 47 US mpg
61.4 – 56.5 UK mpg
21.7 – 20 km/l
Fuel consumption (economy) – extra urban (NEDC) 3.7-4.5 l/100 km
63.6 – 52.3 US mpg
76.3 – 62.8 UK mpg
27 – 22.2 km/l
Fuel consumption (economy) – combined (NEDC) 4.1-4.6 l/100 km
57.4 – 51.1 US mpg
68.9 – 61.4 UK mpg
24.4 – 21.7 km/l
CO2 emissions (NEDC) 119-121 g/km
Fuel Type Diesel
Emission standard Euro 5
Weight-to-power ratio 15.8 kg/Hp, 63.3 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 153.3 Nm/tonne
Engine specs
Power 95 Hp @ 3600 rpm.
Power per litre 60.9 Hp/l
Torque 230 Nm @ 1500-2000 rpm.
169.64 lb.-ft. @ 1500-2000 rpm.
Engine layout Front, Transverse
Engine Model/Code Duratorq / TZGA, TZGB
Engine displacement 1560 cm3
95.2 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 88.3 mm
3.48 in.
Compression ratio 16:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain SOHC
Engine oil capacity 6.2 l
6.55 US qt | 5.46 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.3 l
7.71 US qt | 6.42 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1500-1564 kg
3306.93 – 3448.03 lbs.
Max. weight 2270-2300 kg
5004.49 – 5070.63 lbs.
Max load 736-770 kg
1622.6 – 1697.56 lbs.
Trunk (boot) space – minimum 322 l
11.37 cu. ft.
Trunk (boot) space – maximum 2761 l
97.5 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4818 mm
189.69 in.
Width 1835 mm
72.24 in.
Width including mirrors 2137 mm
84.13 in.
Height 1840-1845 mm
72.44 – 72.64 in.
Wheelbase 3062 mm
120.55 in.
Front track 1568 mm
61.73 in.
Rear (Back) track 1584 mm
62.36 in.
Front overhang 878 mm
34.57 in.
Rear overhang 878 mm
34.57 in.
Ride height (ground clearance) 163 mm
6.42 in.
Minimum turning circle (turning diameter) 12.5 m
41.01 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Coil spring, Torsion
Front brakes Ventilated discs, 320×25 mm
Rear brakes Disc, 280×11 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/60 R16
Wheel rims size 6.5J x 16
