Specifications: Jeep Grand Cherokee IV (WK2, facelift 2017) 5.7 V8 (352 Hp) 4×4 Automatic 2017, 2018

2017 Jeep Grand Cherokee IV (WK2, facelift 2017) - Photo 1

Jeep Grand Cherokee IV (WK2, facelift 2017) 5.7 V8 (352 Hp) 4×4 Automatic – Full specifications
General information
Brand Jeep
Model Grand Cherokee
Generation Grand Cherokee IV (WK2, facelift 2017)
Modification (Engine) 5.7 V8 (352 Hp) 4×4 Automatic
Start of production 2017 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 19.6 l/100 km
12 US mpg
14.41 UK mpg
5.1 km/l
Fuel consumption (economy) – extra urban (NEDC) 9.2 l/100 km
25.57 US mpg
30.7 UK mpg
10.87 km/l
Fuel consumption (economy) – combined (NEDC) 13 l/100 km
18.09 US mpg
21.73 UK mpg
7.69 km/l
CO2 emissions (NEDC) 304 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.3 sec
Acceleration 0 – 62 mph 7.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.9 sec
Maximum speed 225 km/h
139.81 mph
Emission standard Euro 6
Weight-to-power ratio 6.6 kg/Hp, 152.6 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 225.4 Nm/tonne
Engine specs
Power 352 Hp @ 5200 rpm.
Power per litre 62.3 Hp/l
Torque 520 Nm @ 4200 rpm.
383.53 lb.-ft. @ 4200 rpm.
Maximum engine speed 5800 rpm.
Engine layout Front, Longitudinal
Engine Model/Code HEMI / EZH
Engine displacement 5654 cm3
345.03 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 99.5 mm
3.92 in.
Piston Stroke 90.9 mm
3.58 in.
Compression ratio 10.5:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain OHV, VVT
Engine oil capacity 6.6 l
6.97 US qt | 5.81 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 14.6 l
15.43 US qt | 12.85 UK qt
Engine systems Cylinder deactivation system

Space, Volume and weights
Kerb Weight 2307-2424 kg
5086.06 – 5344.01 lbs.
Max. weight 2949 kg
6501.43 lbs.
Max load 525-642 kg
1157.43 – 1415.37 lbs.
Trunk (boot) space – minimum 800 l
28.25 cu. ft.
Trunk (boot) space – maximum 1689 l
59.65 cu. ft.
Fuel tank capacity 93.5 l
24.7 US gal | 20.57 UK gal
Permitted trailer load with brakes (12%) 2949-3500 kg
6501.43 – 7716.18 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4828 mm
190.08 in.
Width 1943 mm
76.5 in.
Width including mirrors 2156 mm
84.88 in.
Height 1792-1802 mm
70.55 – 70.94 in.
Wheelbase 2915 mm
114.76 in.
Front track 1628 mm
64.09 in.
Rear (Back) track 1634 mm
64.33 in.
Ride height (ground clearance) 207-270 mm
8.15 – 10.63 in.
Drag coefficient (Cd) 0.371
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Approach angle 26.3-35.8°
Departure angle 26.5-29.5°
Ramp-over (brakeover) angle 18.8-23.5°
Wading depth 508 mm
20 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission
Front suspension Double wishbone, Transverse stabilizer, Air suspension
Rear suspension Independent multi-link suspension, Air suspension, Transverse stabilizer
Front brakes Ventilated discs, 350×32 mm
Rear brakes Ventilated discs, 330×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 265/50 R20
Wheel rims size 8J x 20
