Specifications: Jeep Grand Cherokee L V (WL) 3.6 V6 Pentastar (290 Hp) 4×4 TorqueFlite 2021, 2022, 2023, 2024, 2025

2021 Jeep Grand Cherokee L V (WL) - Photo 1

Jeep Grand Cherokee L V (WL) 3.6 V6 Pentastar (290 Hp) 4×4 TorqueFlite – Full specifications
General information
Brand Jeep
Model Grand Cherokee
Generation Grand Cherokee L V (WL)
Modification (Engine) 3.6 V6 Pentastar (290 Hp) 4×4 TorqueFlite
Start of production January, 2021 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 13.1 l/100 km
17.96 US mpg
21.56 UK mpg
7.63 km/l
Fuel consumption (economy) – extra urban 9.4 l/100 km
25.02 US mpg
30.05 UK mpg
10.64 km/l
Fuel consumption (economy) – combined 11.2 l/100 km
21 US mpg
25.22 UK mpg
8.93 km/l
Fuel Type Petrol (Gasoline)
Emission standard LEV II+
Weight-to-power ratio 7.4 kg/Hp, 134.7 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 161.6 Nm/tonne
Engine specs
Power 290 Hp @ 6400 rpm.
Power per litre 80.5 Hp/l
Torque 348 Nm @ 4000 rpm.
256.67 lb.-ft. @ 4000 rpm.
Maximum engine speed 6700 rpm.
Engine layout Front, Longitudinal
Engine displacement 3604 cm3
219.93 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 83 mm
3.27 in.
Compression ratio 11.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Valvetrain DOHC
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10.2 l
10.78 US qt | 8.97 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 2153-2307 kg
4746.55 – 5086.06 lbs.
Max. weight 3039 kg
6699.85 lbs.
Max load 732-886 kg
1613.78 – 1953.3 lbs.
Trunk (boot) space – minimum 487 l
17.2 cu. ft.
Trunk (boot) space – maximum 2396 l
84.61 cu. ft.
Fuel tank capacity 87 l
22.98 US gal | 19.14 UK gal
Permitted trailer load with brakes (12%) 2812 kg
6199.4 lbs.
Dimensions
Length 5204 mm
204.88 in.
Width 1979 mm
77.91 in.
Width with mirrors folded 1964 mm
77.32 in.
Width including mirrors 2149 mm
84.61 in.
Height 1815-1817 mm
71.46 – 71.54 in.
Wheelbase 3091 mm
121.69 in.
Front track 1660 mm
65.35 in.
Rear (Back) track 1660 mm
65.35 in.
Ride height (ground clearance) 215-276 mm
8.46 – 10.87 in.
Drag coefficient (Cd) 0.357
Minimum turning circle (turning diameter) 11.7 m
38.39 ft.
Approach angle 20.6-30.1°
Departure angle 21.5-23.6°
Ramp-over (brakeover) angle 18.2-22.6°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission TorqueFlite
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs, 354×28 mm
Rear brakes Ventilated discs, 350×22 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 265/60 R18; 265/50 R20; 275/45 R21
Wheel rims size 8J x 18; 8.5J x 20; 9J x 21
