Specifications: Kia Carens II 2.0i 16V (144 Hp) 2006, 2007, 2008, 2009, 2010

2006 Kia Carens II - Photo 1

Kia Carens II 2.0i 16V (144 Hp) – Full specifications
General information
Brand Kia
Model Carens
Generation Carens II
Modification (Engine) 2.0i 16V (144 Hp)
Start of production 2006 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body type MPV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 10.8 l/100 km
21.78 US mpg
26.16 UK mpg
9.26 km/l
Fuel consumption (economy) – extra urban 6.6 l/100 km
35.64 US mpg
42.8 UK mpg
15.15 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11 sec
Acceleration 0 – 62 mph 11 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 190 km/h
118.06 mph
Weight-to-power ratio 10.3 kg/Hp, 96.6 Hp/tonne
Weight-to-torque ratio 7.9 kg/Nm, 126.8 Nm/tonne
Engine specs
Power 144 Hp @ 6000 rpm.
Power per litre 72.1 Hp/l
Torque 189 Nm @ 4250 rpm.
139.4 lb.-ft. @ 4250 rpm.
Engine layout Front, Transverse
Engine Model/Code Theta II / G4KA
Engine displacement 1998 cm3
121.93 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 86 mm
3.39 in.
Piston Stroke 86 mm
3.39 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.7 l
7.08 US qt | 5.9 UK qt

Space, Volume and weights
Kerb Weight 1490 kg
3284.89 lbs.
Max. weight 2155 kg
4750.96 lbs.
Max load 665 kg
1466.07 lbs.
Trunk (boot) space – minimum 400 l
14.13 cu. ft.
Trunk (boot) space – maximum 2106 l
74.37 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4545 mm
178.94 in.
Width 1820 mm
71.65 in.
Height 1650 mm
64.96 in.
Wheelbase 2690 mm
105.91 in.
Front track 1575 mm
62.01 in.
Rear (Back) track 1570 mm
61.81 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Tires size 205/60 R16
Wheel rims size 16
