Specifications: Kia Carnival II (VQ, facelift 2010) 3.8i V6 (254 Hp) Automatic 2010, 2011, 2012, 2013, 2014

2010 Kia Carnival II (VQ, facelift 2010) - Photo 1

Kia Carnival II (VQ, facelift 2010) 3.8i V6 (254 Hp) Automatic – Full specifications
General information
Brand Kia
Model Carnival
Generation Carnival II (VQ, facelift 2010)
Modification (Engine) 3.8i V6 (254 Hp) Automatic
Start of production 2010 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – urban 13.1 l/100 km
17.96 US mpg
21.56 UK mpg
7.63 km/l
Fuel consumption (economy) – extra urban 9.4 l/100 km
25.02 US mpg
30.05 UK mpg
10.64 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10 sec
Acceleration 0 – 62 mph 10 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.5 sec
Maximum speed 180 km/h
111.85 mph
Weight-to-power ratio 7.8 kg/Hp, 127.6 Hp/tonne
Weight-to-torque ratio 5.8 kg/Nm, 172.4 Nm/tonne
Engine specs
Power 254 Hp @ 6000 rpm.
Power per litre 67.2 Hp/l
Torque 343 Nm @ 3500 rpm.
252.98 lb.-ft. @ 3500 rpm.
Engine layout Front, Transverse
Engine Model/Code Lambda / G6DA
Engine displacement 3778 cm3
230.55 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 87 mm
3.43 in.
Compression ratio 10.4:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 5.2 l
5.49 US qt | 4.58 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.6 l
9.09 US qt | 7.57 UK qt

Space, Volume and weights
Kerb Weight 1990 kg
4387.2 lbs.
Trunk (boot) space – minimum 364 l
12.85 cu. ft.
Trunk (boot) space – maximum 3440 l
121.48 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 4810 mm
189.37 in.
Width 1985 mm
78.15 in.
Height 1750 mm
68.9 in.
Wheelbase 2890 mm
113.78 in.
Front track 1685 mm
66.34 in.
Rear (Back) track 1685 mm
66.34 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Dependent spring suspension with transverse stabilizer
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/70 R16
Wheel rims size 16
