| General information | |
|---|---|
| Brand | Kia |
| Model | Carnival |
| Generation | Carnival IV |
| Modification (Engine) | 2.2d Smartstream (202 Hp) Automatic 9 Seat |
| Start of production | June, 2020 year |
| End of production | October, 2023 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Minivan |
| Seats | 9 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.5 l/100 km 27.67 US mpg 33.23 UK mpg 11.76 km/l |
| Fuel consumption (economy) – extra urban | 6.6-6.7 l/100 km 35.64 – 35.11 US mpg 42.8 – 42.16 UK mpg 15.15 – 14.93 km/l |
| Fuel consumption (economy) – combined | 7.6-7.7 l/100 km 30.95 – 30.55 US mpg 37.17 – 36.69 UK mpg 13.16 – 12.99 km/l |
| CO2 emissions | 146-147 g/km |
| Fuel Type | Diesel |
| Weight-to-power ratio | 10 kg/Hp, 99.5 Hp/tonne |
| Weight-to-torque ratio | 4.6 kg/Nm, 217.2 Nm/tonne |
| Engine specs | |
| Power | 202 Hp @ 3800 rpm. |
| Power per litre | 93.9 Hp/l |
| Torque | 441 Nm @ 1750-2750 rpm. 325.26 lb.-ft. @ 1750-2750 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | Smartstream / D4HE |
| Engine displacement | 2151 cm3 131.26 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil capacity | 5.6 l 5.92 US qt | 4.93 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 8.5 l 8.98 US qt | 7.48 UK qt |
| Engine systems | Start & Stop System |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2030 kg 4475.38 lbs. |
| Dimensions | |
| Length | 5155 mm 202.95 in. |
| Width | 1995 mm 78.54 in. |
| Height | 1740 mm 68.5 in. |
| Wheelbase | 3090 mm 121.65 in. |
| Front track | 1741-1746 mm 68.54 – 68.74 in. |
| Rear (Back) track | 1741-1746 mm 68.54 – 68.74 in. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 8 gears, automatic transmission |
| Front suspension | Independent type McPherson |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/60 R18; 235/55 R19 |
| Wheel rims size | 18; 19 |
