Specifications: Kia Cee’d I 2.0 CVVT (143 Hp) Automatic 2007, 2008, 2009

2007 Kia Cee'd I - Photo 1

Kia Cee’d I 2.0 CVVT (143 Hp) Automatic – Full specifications
General information
Brand Kia
Model Cee’d
Generation Cee’d I
Modification (Engine) 2.0 CVVT (143 Hp) Automatic
Start of production 2007 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 10.2 l/100 km
23.06 US mpg
27.69 UK mpg
9.8 km/l
Fuel consumption (economy) – extra urban (NEDC) 6.3 l/100 km
37.34 US mpg
44.84 UK mpg
15.87 km/l
Fuel consumption (economy) – combined (NEDC) 7.7 l/100 km
30.55 US mpg
36.69 UK mpg
12.99 km/l
CO2 emissions (NEDC) 184 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.4 sec
Acceleration 0 – 62 mph 10.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.9 sec
Maximum speed 195 km/h
121.17 mph
Emission standard Euro 4
Weight-to-power ratio 9.4 kg/Hp, 106 Hp/tonne
Weight-to-torque ratio 7.3 kg/Nm, 137.9 Nm/tonne
Engine specs
Power 143 Hp @ 6000 rpm.
Power per litre 72.4 Hp/l
Torque 186 Nm @ 4600 rpm.
137.19 lb.-ft. @ 4600 rpm.
Engine layout Front, Transverse
Engine Model/Code G4GC
Engine displacement 1975 cm3
120.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 93.5 mm
3.68 in.
Compression ratio 10.1:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC CVVT
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.3 l
6.66 US qt | 5.54 UK qt

Space, Volume and weights
Kerb Weight 1349-1421 kg
2974.04 – 3132.77 lbs.
Max. weight 1780 kg
3924.23 lbs.
Max load 359-431 kg
791.46 – 950.19 lbs.
Trunk (boot) space – minimum 340 l
12.01 cu. ft.
Trunk (boot) space – maximum 1300 l
45.91 cu. ft.
Fuel tank capacity 53 l
14 US gal | 11.66 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Permitted trailer load without brakes 550 kg
1212.54 lbs.
Permitted towbar download 55 kg
121.25 lbs.
Dimensions
Length 4235 mm
166.73 in.
Width 1790 mm
70.47 in.
Height 1480 mm
58.27 in.
Wheelbase 2650 mm
104.33 in.
Front track 1546 mm
60.87 in.
Rear (Back) track 1544 mm
60.79 in.
Front overhang 865 mm
34.06 in.
Rear overhang 720 mm
28.35 in.
Minimum turning circle (turning diameter) 10.8 m
35.43 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension, Transverse stabilizer
Front brakes Ventilated discs, 280 mm
Rear brakes Disc, 262 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 185/65 R15; 195/65 R15; 205/55 R16; 225/45 R17
Wheel rims size 5.5J x 15; 6J x 16; 7J x 17
