Specifications: Kia Ceed III (facelift 2021) 1.5 T-GDI (140 Hp) Mild Hybrid DCT 2024, 2025

2022 Kia Ceed III (facelift 2021) - Photo 1

Kia Ceed III (facelift 2021) 1.5 T-GDI (140 Hp) Mild Hybrid DCT – Full specifications
General information
Brand Kia
Model Cee’d
Generation Ceed III (facelift 2021)
Modification (Engine) 1.5 T-GDI (140 Hp) Mild Hybrid DCT
Start of production November, 2024 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 7.7 l/100 km
30.55 US mpg
36.69 UK mpg
12.99 km/l
Fuel consumption at Medium speed (WLTP) 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption at high speed (WLTP) 5.1 l/100 km
46.12 US mpg
55.39 UK mpg
19.61 km/l
Fuel consumption at very high speed (WLTP) 6.4 l/100 km
36.75 US mpg
44.14 UK mpg
15.63 km/l
Combined fuel consumption (WLTP) 6 l/100 km
39.2 US mpg
47.08 UK mpg
16.67 km/l
CO2 emissions (WLTP) 137 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.7 sec
Acceleration 0 – 62 mph 9.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.2 sec
Maximum speed 197 km/h
122.41 mph
Emission standard Euro 6e
Weight-to-power ratio 9.4 kg/Hp, 106.5 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 192.4 Nm/tonne
Electric cars and hybrids specs
Battery voltage 48 V
Battery technology Lithium-ion (Li-Ion)
Battery location Under the trunk
Internal combustion engine specs
Power 140 Hp @ 5500 rpm.
Power per litre 94.5 Hp/l
Torque 253 Nm @ 1500-3000 rpm.
186.6 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code Smartstream / G4LK
Engine displacement 1482 cm3
90.44 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71.6 mm
2.82 in.
Piston Stroke 92 mm
3.62 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.1 l
6.45 US qt | 5.37 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1315-1434 kg
2899.08 – 3161.43 lbs.
Max. weight 1860 kg
4100.6 lbs.
Max load 426-545 kg
939.17 – 1201.52 lbs.
Trunk (boot) space – minimum 357 l
12.61 cu. ft.
Trunk (boot) space – maximum 1253 l
44.25 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1210 kg
2667.59 lbs.
Permitted trailer load without brakes 610 kg
1344.82 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4315 mm
169.88 in.
Width 1800 mm
70.87 in.
Width including mirrors 2055 mm
80.91 in.
Height 1447 mm
56.97 in.
Wheelbase 2650 mm
104.33 in.
Front track 1559-1565 mm
61.38 – 61.61 in.
Rear (Back) track 1567-1573 mm
61.69 – 61.93 in.
Front overhang 885 mm
34.84 in.
Rear overhang 780 mm
30.71 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 305×25 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 225/45 R17
Wheel rims size 6.5J x 16; 7J x 17
