Specifications: Kia Ceed III Sportswagon 1.4 T-GDI (140 Hp) 2018, 2019, 2020, 2021

2018 Kia Ceed III Sportswagon - Photo 1

Kia Ceed III Sportswagon 1.4 T-GDI (140 Hp) – Full specifications
General information
Brand Kia
Model Cee’d
Generation Ceed III Sportswagon
Modification (Engine) 1.4 T-GDI (140 Hp)
Start of production June, 2018 year
End of production March, 2021 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC, WLTP equivalent) 7-7.5 l/100 km
33.6 – 31.36 US mpg
40.35 – 37.66 UK mpg
14.29 – 13.33 km/l
Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) 4.8-5 l/100 km
49 – 47.04 US mpg
58.85 – 56.5 UK mpg
20.83 – 20 km/l
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 5.6-5.9 l/100 km
42 – 39.87 US mpg
50.44 – 47.88 UK mpg
17.86 – 16.95 km/l
CO2 emissions (NEDC, WLTP equivalent) 128-135 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.1 sec
Acceleration 0 – 62 mph 9.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.6 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 6d TEMP
Weight-to-power ratio 9.1 kg/Hp, 109.6 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 189.5 Nm/tonne
Engine specs
Power 140 Hp @ 6000 rpm.
Power per litre 103.5 Hp/l
Torque 242 Nm @ 1500-3200 rpm.
178.49 lb.-ft. @ 1500-3200 rpm.
Engine layout Front, Transverse
Engine Model/Code Kappa II / G4LD
Engine displacement 1353 cm3
82.57 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71.6 mm
2.82 in.
Piston Stroke 84 mm
3.31 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.1 l
6.45 US qt | 5.37 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1277-1408 kg
2815.3 – 3104.11 lbs.
Max. weight 1850 kg
4078.55 lbs.
Max load 442-573 kg
974.44 – 1263.25 lbs.
Trunk (boot) space – minimum 625 l
22.07 cu. ft.
Trunk (boot) space – maximum 1694 l
59.82 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1410 kg
3108.52 lbs.
Permitted trailer load without brakes 600 kg
1322.77 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4600 mm
181.1 in.
Width 1800 mm
70.87 in.
Width including mirrors 2055 mm
80.91 in.
Height 1465 mm
57.68 in.
Wheelbase 2650 mm
104.33 in.
Front track 1559-1573 mm
61.38 – 61.93 in.
Rear (Back) track 1567-1581 mm
61.69 – 62.24 in.
Front overhang 880 mm
34.65 in.
Rear overhang 1070 mm
42.13 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 280×23 mm
Rear brakes Disc, 272×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 205/55 R16; 225/45 R17; 225/40 R18
Wheel rims size 6J x 15; 6.5J x 16; 7J x 17; 7.5J x 18
