| General information | |
|---|---|
| Brand | Kia |
| Model | Magentis |
| Generation | Magentis II (facelift 2008) |
| Modification (Engine) | 2.4 CVVT (177 Hp) |
| Start of production | 2009 year |
| End of production | 2010 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Sedan |
| Seats | 5 |
| Doors | 4 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 8.1 kg/Hp, 123.6 Hp/tonne |
| Weight-to-torque ratio | 8.5 kg/Nm, 118 Nm/tonne |
| Engine specs | |
| Power | 177 Hp @ 6000 rpm. |
| Power per litre | 75 Hp/l |
| Torque | 169 Nm @ 4000 rpm. 124.65 lb.-ft. @ 4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | G4KE |
| Engine displacement | 2359 cm3 143.96 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 88 mm 3.46 in. |
| Piston Stroke | 97 mm 3.82 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Multi-port manifold injection |
| Engine aspiration | Naturally aspirated engine |
| Valvetrain | DOHC |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1432 kg 3157.02 lbs. |
| Trunk (boot) space – minimum | 500 l 17.66 cu. ft. |
| Trunk (boot) space – maximum | 816 l 28.82 cu. ft. |
| Fuel tank capacity | 62 l 16.38 US gal | 13.64 UK gal |
| Dimensions | |
| Length | 4800 mm 188.98 in. |
| Width | 1805 mm 71.06 in. |
| Height | 1480 mm 58.27 in. |
| Wheelbase | 2720 mm 107.09 in. |
| Front track | 1560 mm 61.42 in. |
| Rear (Back) track | 1550 mm 61.02 in. |
| Minimum turning circle (turning diameter) | 11.8 m 38.71 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 5 gears, manual transmission |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/60 R16 |
| Wheel rims size | 6.5J x 16 |
