Specifications: Kia Optima IV 1.7 CRDi (141 Hp) DCT 2015, 2016, 2017, 2018

2015 Kia Optima IV - Photo 1

Kia Optima IV 1.7 CRDi (141 Hp) DCT – Full specifications
General information
Brand Kia
Model Optima
Generation Optima IV
Modification (Engine) 1.7 CRDi (141 Hp) DCT
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 5.1 l/100 km
46.12 US mpg
55.39 UK mpg
19.61 km/l
Fuel consumption (economy) – extra urban 4.1 l/100 km
57.37 US mpg
68.9 UK mpg
24.39 km/l
Fuel consumption (economy) – combined 4.4 l/100 km
53.46 US mpg
64.2 UK mpg
22.73 km/l
CO2 emissions 116 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 11 sec
Acceleration 0 – 62 mph 11 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.5 sec
Maximum speed 203 km/h
126.14 mph
Emission standard Euro 6 b
Weight-to-power ratio 10.9 kg/Hp, 92.2 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 222.2 Nm/tonne
Engine specs
Power 141 Hp @ 4000 rpm.
Power per litre 83.7 Hp/l
Torque 340 Nm @ 1750-2500 rpm.
250.77 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Transverse
Engine Model/Code U II / D4FD
Engine displacement 1685 cm3
102.83 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 77.2 mm
3.04 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 15.7:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.3 l
5.6 US qt | 4.66 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.1 l
7.5 US qt | 6.25 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1530 kg
3373.07 lbs.
Max. weight 2080 kg
4585.62 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 510 l
18.01 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Dimensions
Length 4855 mm
191.14 in.
Width 1860 mm
73.23 in.
Height 1465 mm
57.68 in.
Wheelbase 2805 mm
110.43 in.
Front track 1607 mm
63.27 in.
Rear (Back) track 1614 mm
63.54 in.
Ride height (ground clearance) 135 mm
5.31 in.
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/60 R16; 215/55 R17; 235/45 R18
Wheel rims size 16; 17; 18
