Specifications: Kia Picanto II 5D 1.2 16V (85 Hp) automatic 2011, 2012, 2013, 2014, 2015

2011 Kia Picanto II 5D - Photo 1

Kia Picanto II 5D 1.2 16V (85 Hp) automatic – Full specifications
General information
Brand Kia
Model Picanto
Generation Picanto II 5D
Modification (Engine) 1.2 16V (85 Hp) automatic
Start of production 2011 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.7 l/100 km
35.11 US mpg
42.16 UK mpg
14.93 km/l
Fuel consumption (economy) – extra urban 4.5 l/100 km
52.27 US mpg
62.77 UK mpg
22.22 km/l
Fuel consumption (economy) – combined 5.3 l/100 km
44.38 US mpg
53.3 UK mpg
18.87 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 13.4 sec
Acceleration 0 – 62 mph 13.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.7 sec
Maximum speed 163 km/h
101.28 mph
Emission standard Euro 5
Weight-to-power ratio 10.3 kg/Hp, 97.1 Hp/tonne
Weight-to-torque ratio 7.3 kg/Nm, 137.1 Nm/tonne
Engine specs
Power 85 Hp
Power per litre 68.1 Hp/l
Torque 120 Nm @ 4000 rpm.
88.51 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code G4LA
Engine displacement 1248 cm3
76.16 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.1 l
5.39 US qt | 4.49 UK qt

Space, Volume and weights
Kerb Weight 875 kg
1929.04 lbs.
Max. weight 1370 kg
3020.33 lbs.
Max load 495 kg
1091.29 lbs.
Trunk (boot) space – minimum 200 l
7.06 cu. ft.
Trunk (boot) space – maximum 605 l
21.37 cu. ft.
Fuel tank capacity 35 l
9.25 US gal | 7.7 UK gal
Dimensions
Length 3595 mm
141.54 in.
Width 1595 mm
62.8 in.
Height 1480 mm
58.27 in.
Wheelbase 2385 mm
93.9 in.
Front track 1421 mm
55.94 in.
Rear (Back) track 1424 mm
56.06 in.
Minimum turning circle (turning diameter) 9.8 m
32.15 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 165/60 R14
Wheel rims size 14
