Specifications: Kia ProCeed III GT 1.6 T-GDI (204 Hp) DCT 2018, 2019, 2020, 2021

2018 Kia ProCeed III - Photo 1

Kia ProCeed III GT 1.6 T-GDI (204 Hp) DCT – Full specifications
General information
Brand Kia
Model Pro Cee’d
Generation ProCeed III
Modification (Engine) GT 1.6 T-GDI (204 Hp) DCT
Start of production December, 2018 year
End of production September, 2021 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC, WLTP equivalent) 7.1 l/100 km
33.13 US mpg
39.79 UK mpg
14.08 km/l
Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
CO2 emissions (NEDC, WLTP equivalent) 142 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.5 sec
Acceleration 0 – 62 mph 7.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.1 sec
Maximum speed 225 km/h
139.81 mph
Emission standard Euro 6d-TEMP
Weight-to-power ratio 6.7 kg/Hp, 149.7 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 194.4 Nm/tonne
Engine specs
Power 204 Hp @ 6000 rpm.
Power per litre 128.2 Hp/l
Torque 265 Nm @ 1500-4500 rpm.
195.45 lb.-ft. @ 1500-4500 rpm.
Engine layout Front, Transverse
Engine Model/Code Gamma II / G4FJ
Engine displacement 1591 cm3
97.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 77 mm
3.03 in.
Piston Stroke 85.44 mm
3.36 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-scroll turbo, Intercooler
Valvetrain DOHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.8 l
6.13 US qt | 5.1 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1363-1465 kg
3004.9 – 3229.77 lbs.
Max. weight 1900 kg
4188.78 lbs.
Max load 435-537 kg
959.01 – 1183.88 lbs.
Trunk (boot) space – minimum 594 l
20.98 cu. ft.
Trunk (boot) space – maximum 1545 l
54.56 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1410 kg
3108.52 lbs.
Permitted trailer load without brakes 600 kg
1322.77 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4605 mm
181.3 in.
Width 1800 mm
70.87 in.
Width including mirrors 2055 mm
80.91 in.
Height 1422 mm
55.98 in.
Wheelbase 2650 mm
104.33 in.
Front track 1555 mm
61.22 in.
Rear (Back) track 1563 mm
61.54 in.
Front overhang 885 mm
34.84 in.
Rear overhang 1070 mm
42.13 in.
Ride height (ground clearance) 135 mm
5.31 in.
Minimum turning circle (turning diameter) 10 m
32.81 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 320×28 mm
Rear brakes Disc, 284×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/40 ZR18
Wheel rims size 7.5J x 18
