Specifications: Kia Rio III Hatchback (UB, facelift 2015) 3 door 1.1 CRDI (75 Hp) ISG 2015, 2016, 2017

2015 Kia Rio III Hatchback (UB, facelift 2015) 3 door - Photo 1

Kia Rio III Hatchback (UB, facelift 2015) 3 door 1.1 CRDI (75 Hp) ISG – Full specifications
General information
Brand Kia
Model Rio
Generation Rio III Hatchback (UB, facelift 2015) 3 door
Modification (Engine) 1.1 CRDI (75 Hp) ISG
Start of production 2015 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 3
Performance specs
Fuel consumption (economy) – urban 4.1 l/100 km
57.37 US mpg
68.9 UK mpg
24.39 km/l
Fuel consumption (economy) – extra urban 3.3 l/100 km
71.28 US mpg
85.6 UK mpg
30.3 km/l
Fuel consumption (economy) – combined 3.6 l/100 km
65.34 US mpg
78.47 UK mpg
27.78 km/l
CO2 emissions 94 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 16.5 sec
Acceleration 0 – 62 mph 16.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 15.7 sec
Maximum speed 160 km/h
99.42 mph
Emission standard Euro 6
Weight-to-power ratio 15 kg/Hp, 66.7 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 151.1 Nm/tonne
Engine specs
Power 75 Hp @ 4000 rpm.
Power per litre 67 Hp/l
Torque 170 Nm @ 1500-2750 rpm.
125.39 lb.-ft. @ 1500-2750 rpm.
Engine layout Front, Transverse
Engine Model/Code D3FA
Engine displacement 1120 cm3
68.35 cu. in.
Number of cylinders 3
Engine configuration Inline
Cylinder Bore 75 mm
2.95 in.
Piston Stroke 84.5 mm
3.33 in.
Compression ratio 17.8:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.8 l
5.07 US qt | 4.22 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.4 l
6.76 US qt | 5.63 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1125-1205 kg
2480.2 – 2656.57 lbs.
Max. weight 1640 kg
3615.58 lbs.
Max load 435-515 kg
959.01 – 1135.38 lbs.
Trunk (boot) space – minimum 288 l
10.17 cu. ft.
Trunk (boot) space – maximum 923 l
32.6 cu. ft.
Fuel tank capacity 43 l
11.36 US gal | 9.46 UK gal
Max. roof load 70 kg
154.32 lbs.
Permitted trailer load with brakes (12%) 800 kg
1763.7 lbs.
Permitted trailer load without brakes 450 kg
992.08 lbs.
Permitted towbar download 50 kg
110.23 lbs.
Dimensions
Length 4050 mm
159.45 in.
Width 1720 mm
67.72 in.
Width including mirrors 1985 mm
78.15 in.
Height 1455 mm
57.28 in.
Wheelbase 2570 mm
101.18 in.
Front track 1507-1520 mm
59.33 – 59.84 in.
Rear (Back) track 1511-1525 mm
59.49 – 60.04 in.
Front overhang 810 mm
31.89 in.
Rear overhang 670 mm
26.38 in.
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 185/65 R15; 195/55 R16; 205/45 R17
Wheel rims size 5.5J x 15; 6.0J x 16; 6.5J x 17
