Specifications: Kia Rio III Sedan (UB) 1.1 CRDi 12V (75 Hp) 2011, 2012, 2013, 2014, 2015

2011 Kia Rio III Sedan (UB) - Photo 1

Kia Rio III Sedan (UB) 1.1 CRDi 12V (75 Hp) – Full specifications
General information
Brand Kia
Model Rio
Generation Rio III Sedan (UB)
Modification (Engine) 1.1 CRDi 12V (75 Hp)
Start of production June, 2011 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel Type Diesel
Acceleration 0 – 100 km/h 16.1 sec
Acceleration 0 – 62 mph 16.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 15.3 sec
Maximum speed 160 km/h
99.42 mph
Emission standard Euro 5
Weight-to-power ratio 14.9 kg/Hp, 67.2 Hp/tonne
Weight-to-torque ratio 6.6 kg/Nm, 152.3 Nm/tonne
Engine specs
Power 75 Hp
Power per litre 67 Hp/l
Torque 170 Nm @ 1500 rpm.
125.39 lb.-ft. @ 1500 rpm.
Engine layout Front, Transverse
Engine Model/Code D3FA
Engine displacement 1120 cm3
68.35 cu. in.
Number of cylinders 3
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.8 l
5.07 US qt | 4.22 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.4 l
6.76 US qt | 5.63 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1116 kg
2460.36 lbs.
Max. weight 1640 kg
3615.58 lbs.
Max load 524 kg
1155.22 lbs.
Trunk (boot) space – minimum 500 l
17.66 cu. ft.
Fuel tank capacity 43 l
11.36 US gal | 9.46 UK gal
Dimensions
Length 4370 mm
172.05 in.
Width 1700 mm
66.93 in.
Height 1470 mm
57.87 in.
Wheelbase 2570 mm
101.18 in.
Front track 1495 mm
58.86 in.
Rear (Back) track 1502 mm
59.13 in.
Minimum turning circle (turning diameter) 10.5 m
34.45 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 185/65 R15; 195/55 R16; 205/45 R17
Wheel rims size 15; 16; 17
