Specifications: Kia Rio IV Hatchback (YB) 1.25 MPI (84 Hp) 2017, 2018, 2019, 2020

2017 Kia Rio IV Hatchback (YB) - Photo 1

Kia Rio IV Hatchback (YB) 1.25 MPI (84 Hp) – Full specifications
General information
Brand Kia
Model Rio
Generation Rio IV Hatchback (YB)
Modification (Engine) 1.25 MPI (84 Hp)
Start of production February, 2017 year
End of production July, 2020 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined 4.7-4.8 l/100 km
50.05 – 49 US mpg
60.1 – 58.85 UK mpg
21.28 – 20.83 km/l
CO2 emissions 106-109 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 12.9 sec
Acceleration 0 – 62 mph 12.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 12.3 sec
Maximum speed 170 km/h
105.63 mph
Emission standard Euro 6 b
Weight-to-power ratio 13.2 kg/Hp, 75.7 Hp/tonne
Weight-to-torque ratio 9.1 kg/Nm, 109.9 Nm/tonne
Engine specs
Power 84 Hp @ 6000 rpm.
Power per litre 67.3 Hp/l
Torque 122 Nm @ 4000 rpm.
89.98 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code G4LA
Engine displacement 1248 cm3
76.16 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71 mm
2.8 in.
Piston Stroke 78.8 mm
3.1 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 3.6 l
3.8 US qt | 3.17 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.1 l
5.39 US qt | 4.49 UK qt

Space, Volume and weights
Kerb Weight 1110 kg
2447.13 lbs.
Max. weight 1560 kg
3439.21 lbs.
Max load 450 kg
992.08 lbs.
Trunk (boot) space – minimum 325 l
11.48 cu. ft.
Trunk (boot) space – maximum 980 l
34.61 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Permitted trailer load with brakes (12%) 910 kg
2006.21 lbs.
Permitted trailer load without brakes 450 kg
992.08 lbs.
Dimensions
Length 4065 mm
160.04 in.
Width 1725 mm
67.91 in.
Height 1450 mm
57.09 in.
Wheelbase 2580 mm
101.57 in.
Front track 1518 mm
59.76 in.
Rear (Back) track 1524 mm
60 in.
Front overhang 830 mm
32.68 in.
Rear overhang 655 mm
25.79 in.
Ride height (ground clearance) 135 mm
5.31 in.
Minimum turning circle (turning diameter) 10.2 m
33.46 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring, Elastic beam
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 185/65 R15; 195/55 R16; 205/45 R17
Wheel rims size 15; 16; 17
