Specifications: Kia Sedona II SWB 3.8 V6 (248 Hp) Automatic 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014

2006 Kia Sedona II SWB - Photo 1

Kia Sedona II SWB 3.8 V6 (248 Hp) Automatic – Full specifications
General information
Brand Kia
Model Sedona
Generation Sedona II SWB
Modification (Engine) 3.8 V6 (248 Hp) Automatic
Start of production 2006 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 7-8
Doors 5
Performance specs
Fuel consumption (economy) – urban 13.8 l/100 km
17.04 US mpg
20.47 UK mpg
7.25 km/l
Fuel consumption (economy) – extra urban 10.2 l/100 km
23.06 US mpg
27.69 UK mpg
9.8 km/l
Fuel consumption (economy) – combined 12.4 l/100 km
18.97 US mpg
22.78 UK mpg
8.06 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.7 sec
Acceleration 0 – 62 mph 8.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.3 sec
Maximum speed 213 km/h
132.35 mph
Emission standard Euro 4
Weight-to-power ratio 8 kg/Hp, 125.3 Hp/tonne
Weight-to-torque ratio 5.8 kg/Nm, 173.2 Nm/tonne
Engine specs
Power 248 Hp @ 6000 rpm.
Power per litre 65.6 Hp/l
Torque 343 Nm @ 3500 rpm.
252.98 lb.-ft. @ 3500 rpm.
Engine layout Front, Transverse
Engine displacement 3778 cm3
230.55 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 96 mm
3.78 in.
Piston Stroke 87 mm
3.43 in.
Compression ratio 10.4:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC

Space, Volume and weights
Kerb Weight 1980 kg
4365.15 lbs.
Max. weight 2675 kg
5897.37 lbs.
Max load 695 kg
1532.21 lbs.
Trunk (boot) space – minimum 1750 l
61.8 cu. ft.
Trunk (boot) space – maximum 3435 l
121.31 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 4810 mm
189.37 in.
Width 1985 mm
78.15 in.
Height 1815 mm
71.46 in.
Wheelbase 2890 mm
113.78 in.
Front track 1685 mm
66.34 in.
Rear (Back) track 1685 mm
66.34 in.
Drag coefficient (Cd) 0.34
Minimum turning circle (turning diameter) 11.64 m
38.19 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Tires size 225/70 R16
Wheel rims size 16
