| General information | |
|---|---|
| Brand | Kia |
| Model | Sportage |
| Generation | Sportage II |
| Modification (Engine) | 2.0 CRDi (113 Hp) 4WD |
| Start of production | 2004 year |
| End of production | 2005 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Fuel consumption (economy) – urban | 8.9 l/100 km 26.43 US mpg 31.74 UK mpg 11.24 km/l |
| Fuel consumption (economy) – extra urban | 6.2 l/100 km 37.94 US mpg 45.56 UK mpg 16.13 km/l |
| Fuel consumption (economy) – combined | 7.1 l/100 km 33.13 US mpg 39.79 UK mpg 14.08 km/l |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 13.8 sec |
| Acceleration 0 – 62 mph | 13.8 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 13.1 sec |
| Maximum speed | 167 km/h 103.77 mph |
| Weight-to-power ratio | 15.6 kg/Hp, 64.3 Hp/tonne |
| Weight-to-torque ratio | 7 kg/Nm, 142.2 Nm/tonne |
| Engine specs | |
| Power | 113 Hp @ 4000 rpm. |
| Power per litre | 56.8 Hp/l |
| Torque | 250 Nm @ 1800-2500 rpm. 184.39 lb.-ft. @ 1800-2500 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | D4EA |
| Engine displacement | 1991 cm3 121.5 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 83 mm 3.27 in. |
| Piston Stroke | 92 mm 3.62 in. |
| Compression ratio | 17.7:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | OHC |
| Engine oil capacity | 5.9 l 6.23 US qt | 5.19 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.9 l 8.35 US qt | 6.95 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1758 kg 3875.73 lbs. |
| Max. weight | 2210 kg 4872.22 lbs. |
| Max load | 452 kg 996.49 lbs. |
| Fuel tank capacity | 58 l 15.32 US gal | 12.76 UK gal |
| Dimensions | |
| Length | 4350 mm 171.26 in. |
| Width | 1840 mm 72.44 in. |
| Height | 1730 mm 68.11 in. |
| Wheelbase | 2630 mm 103.54 in. |
| Front track | 1550 mm 61.02 in. |
| Rear (Back) track | 1550 mm 61.02 in. |
| Drivetrain, brakes and suspension specs | |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 6 gears, manual transmission |
| Front suspension | Spring Strut |
| Rear suspension | Double wishbone |
| Front brakes | Ventilated discs |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 235/60 R16 |
| Wheel rims size | 6.5 X 16 |
