Specifications: Kia Sportage IV 2.0 CRDi (185 Hp) AWD 2016, 2017, 2018

2016 Kia Sportage IV - Photo 1

Kia Sportage IV 2.0 CRDi (185 Hp) AWD – Full specifications
General information
Brand Kia
Model Sportage
Generation Sportage IV
Modification (Engine) 2.0 CRDi (185 Hp) AWD
Start of production 2016 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (NEDC) 7.1 l/100 km
33.13 US mpg
39.79 UK mpg
14.08 km/l
Fuel consumption (economy) – extra urban (NEDC) 5.2 l/100 km
45.23 US mpg
54.32 UK mpg
19.23 km/l
Fuel consumption (economy) – combined (NEDC) 5.9 l/100 km
39.87 US mpg
47.88 UK mpg
16.95 km/l
CO2 emissions (NEDC) 154 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.5 sec
Acceleration 0 – 62 mph 9.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9 sec
Maximum speed 201 km/h
124.9 mph
Emission standard Euro 6 b
Weight-to-power ratio 8.2 kg/Hp, 122.4 Hp/tonne
Weight-to-torque ratio 3.8 kg/Nm, 264.6 Nm/tonne
Engine specs
Power 185 Hp @ 4000 rpm.
Power per litre 92.7 Hp/l
Torque 400 Nm @ 1750-2750 rpm.
295.02 lb.-ft. @ 1750-2750 rpm.
Engine layout Front, Transverse
Engine Model/Code R II / D4HA
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 7.6 l
8.03 US qt | 6.69 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.7 l
9.19 US qt | 7.65 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1512-1681 kg
3333.39 – 3705.97 lbs.
Max. weight 2250 kg
4960.4 lbs.
Max load 569-738 kg
1254.43 – 1627.01 lbs.
Trunk (boot) space – minimum 491 l
17.34 cu. ft.
Trunk (boot) space – maximum 1492 l
52.69 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2200 kg
4850.17 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4480 mm
176.38 in.
Width 1855 mm
73.03 in.
Width including mirrors 2085 mm
82.09 in.
Height 1645 mm
64.76 in.
Wheelbase 2670 mm
105.12 in.
Front track 1609-1625 mm
63.35 – 63.98 in.
Rear (Back) track 1620-1636 mm
63.78 – 64.41 in.
Front overhang 910 mm
35.83 in.
Rear overhang 900 mm
35.43 in.
Ride height (ground clearance) 172 mm
6.77 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Approach angle 16.7°
Departure angle 23.9°
Ramp-over (brakeover) angle 18.6°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 305 mm
Rear brakes Disc, 302 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/70 R16; 225/60 R17; 245/45 R19
Wheel rims size 6.5J x 16; 7J x 17; 7.5J x 19
