Specifications: Kia Venga (YN, facelift 2014) 1.6 (125 Hp) 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024

2014 Kia Venga (YN, facelift 2014) - Photo 1

Kia Venga (YN, facelift 2014) 1.6 (125 Hp) – Full specifications
General information
Brand Kia
Model Venga
Generation Venga (YN, facelift 2014)
Modification (Engine) 1.6 (125 Hp)
Start of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.4 l/100 km
31.79 US mpg
38.17 UK mpg
13.51 km/l
Fuel consumption (economy) – extra urban 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – combined 6.4 l/100 km
36.75 US mpg
44.14 UK mpg
15.63 km/l
CO2 emissions 148 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.9 sec
Acceleration 0 – 62 mph 10.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.4 sec
Maximum speed 185 km/h
114.95 mph
Emission standard Euro 6
Weight-to-power ratio 9.4 kg/Hp, 105.9 Hp/tonne
Weight-to-torque ratio 7.6 kg/Nm, 132.2 Nm/tonne
Engine specs
Power 125 Hp @ 6300 rpm.
Power per litre 78.6 Hp/l
Torque 156 Nm @ 4200 rpm.
115.06 lb.-ft. @ 4200 rpm.
Engine layout Front, Transverse
Engine Model/Code G4FC
Engine displacement 1591 cm3
97.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 77 mm
3.03 in.
Piston Stroke 85.44 mm
3.36 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 3.3 l
3.49 US qt | 2.9 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 5.3 l
5.6 US qt | 4.66 UK qt

Space, Volume and weights
Kerb Weight 1180-1280 kg
2601.45 – 2821.92 lbs.
Max. weight 1710 kg
3769.9 lbs.
Max load 430-530 kg
947.99 – 1168.45 lbs.
Trunk (boot) space – minimum 314 l
11.09 cu. ft.
Trunk (boot) space – maximum 1486 l
52.48 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 70 kg
154.32 lbs.
Permitted trailer load with brakes (12%) 1300 kg
2866.01 lbs.
Permitted trailer load without brakes 550 kg
1212.54 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4075 mm
160.43 in.
Width 1765 mm
69.49 in.
Width including mirrors 2020 mm
79.53 in.
Height 1600 mm
62.99 in.
Wheelbase 2615 mm
102.95 in.
Front track 1541-1553 mm
60.67 – 61.14 in.
Rear (Back) track 1545-1557 mm
60.83 – 61.3 in.
Front overhang 792 mm
31.18 in.
Rear overhang 668 mm
26.3 in.
Minimum turning circle (turning diameter) 10.42 m
34.19 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 205/55 R16; 205/50 R17
Wheel rims size 6.0J X 15; 6.0J X 16; 6.5J X 17
