Specifications: Kia Xceed (facelift 2022) 1.5 T-GDI (140 Hp) DCT 2024, 2025

2023 Kia Xceed (facelift 2022) - Photo 1

Kia Xceed (facelift 2022) 1.5 T-GDI (140 Hp) DCT – Full specifications
General information
Brand Kia
Model XCeed
Generation Xceed (facelift 2022)
Modification (Engine) 1.5 T-GDI (140 Hp) DCT
Start of production May, 2024 year
End of production July, 2025 year
Powertrain Architecture Internal Combustion engine
Body type SUV, Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption at Low speed (WLTP) 8.3 l/100 km
28.34 US mpg
34.03 UK mpg
12.05 km/l
Fuel consumption at Medium speed (WLTP) 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
Fuel consumption at high speed (WLTP) 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
Fuel consumption at very high speed (WLTP) 6.9 l/100 km
34.09 US mpg
40.94 UK mpg
14.49 km/l
Combined fuel consumption (WLTP) 6.5 l/100 km
36.19 US mpg
43.46 UK mpg
15.38 km/l
CO2 emissions (WLTP) 148 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.4 sec
Acceleration 0 – 62 mph 10.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.9 sec
Maximum speed 195 km/h
121.17 mph
Emission standard Euro 6e
Weight-to-power ratio 9.5 kg/Hp, 105.7 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 190.9 Nm/tonne
Engine specs
Power 140 Hp @ 5500 rpm.
Power per litre 94.5 Hp/l
Torque 253 Nm @ 1500-3000 rpm.
186.6 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code G4LH
Engine displacement 1482 cm3
90.44 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 71.6 mm
2.82 in.
Piston Stroke 92 mm
3.62 in.
Compression ratio 10.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.1 l
6.45 US qt | 5.37 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1325-1446 kg
2921.12 – 3187.88 lbs.
Max. weight 1870 kg
4122.64 lbs.
Max load 424-545 kg
934.76 – 1201.52 lbs.
Trunk (boot) space – minimum 426 l
15.04 cu. ft.
Trunk (boot) space – maximum 1378 l
48.66 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1210 kg
2667.59 lbs.
Permitted trailer load without brakes 610 kg
1344.82 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4395 mm
173.03 in.
Width 1826 mm
71.89 in.
Height 1495 mm
58.86 in.
Wheelbase 2650 mm
104.33 in.
Front track 1575 mm
62.01 in.
Rear (Back) track 1573 mm
61.93 in.
Front overhang 905 mm
35.63 in.
Rear overhang 840 mm
33.07 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Independent type McPherson
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 305×25 mm
Rear brakes Disc, 284×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/45 R18 94V
Wheel rims size 7.5J x 18 ET45
