Specifications: Kia Xceed (facelift 2022) 1.6 CRDi (136 Hp) Mild Hybrid DCT 2022, 2023

2023 Kia Xceed (facelift 2022) - Photo 1

Kia Xceed (facelift 2022) 1.6 CRDi (136 Hp) Mild Hybrid DCT – Full specifications
General information
Brand Kia
Model XCeed
Generation Xceed (facelift 2022)
Modification (Engine) 1.6 CRDi (136 Hp) Mild Hybrid DCT
Start of production July, 2022 year
End of production November, 2023 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type SUV, Crossover
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 5-5.2 l/100 km
47.04 – 45.23 US mpg
56.5 – 54.32 UK mpg
20 – 19.23 km/l
CO2 emissions (WLTP) 130-136 g/km
Fuel consumption (economy) – urban (NEDC, WLTP equivalent) 4.5-4.7 l/100 km
52.27 – 50.05 US mpg
62.77 – 60.1 UK mpg
22.22 – 21.28 km/l
Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) 4.4 l/100 km
53.46 US mpg
64.2 UK mpg
22.73 km/l
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 4.4-4.6 l/100 km
53.46 – 51.13 US mpg
64.2 – 61.41 UK mpg
22.73 – 21.74 km/l
CO2 emissions (NEDC, WLTP equivalent) 116-121 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.1 sec
Acceleration 0 – 62 mph 10.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.6 sec
Maximum speed 198 km/h
123.03 mph
Emission standard Euro 6d
Weight-to-power ratio 10.3 kg/Hp, 97.4 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 229.1 Nm/tonne
Electric cars and hybrids specs
Battery voltage 48 V
Battery technology Lithium-polymer (LiPo)
Internal combustion engine specs
Power 136 Hp @ 4000 rpm.
Power per litre 85.1 Hp/l
Torque 320 Nm @ 2000-2250 rpm.
236.02 lb.-ft. @ 2000-2250 rpm.
Engine layout Front, Transverse
Engine Model/Code D4FE
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 77 mm
3.03 in.
Piston Stroke 85.8 mm
3.38 in.
Compression ratio 15.9:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.4 l
4.65 US qt | 3.87 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.7 l
8.14 US qt | 6.78 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1397-1511 kg
3079.86 – 3331.18 lbs.
Max. weight 1950 kg
4299.01 lbs.
Max load 439-553 kg
967.83 – 1219.16 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1332 l
47.04 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
AdBlue tank 12 l
3.17 US gal | 2.64 UK gal
Max. roof load 80 kg
176.37 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 650 kg
1433 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4395 mm
173.03 in.
Width 1826 mm
71.89 in.
Height 1483-1495 mm
58.39 – 58.86 in.
Wheelbase 2650 mm
104.33 in.
Front track 1575-1585 mm
62.01 – 62.4 in.
Rear (Back) track 1573-1583 mm
61.93 – 62.32 in.
Front overhang 905 mm
35.63 in.
Rear overhang 840 mm
33.07 in.
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Independent type McPherson
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs, 305×25 mm
Rear brakes Disc, 284×10 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/60 R16 92H; 235/45 R18 94V
Wheel rims size 6.5J x 16 ET40; 7.5J x 18 ET45
