Specifications: Land Rover Discovery Sport 2.0 (150 Hp) AWD Automatic Ingenium engine 7 Seat 2016, 2017, 2018

2015 Land Rover Discovery Sport - Photo 1

Land Rover Discovery Sport 2.0 (150 Hp) AWD Automatic Ingenium engine 7 Seat – Full specifications
General information
Brand Land Rover
Model Discovery Sport
Generation Discovery Sport
Modification (Engine) 2.0 (150 Hp) AWD Automatic Ingenium engine 7 Seat
Start of production 2016 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 7
Doors 5
Performance specs
Fuel consumption (economy) – combined 4.7 l/100 km
50 US mpg
60.1 UK mpg
21.3 km/l
CO2 emissions 123 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.3 sec
Acceleration 0 – 62 mph 10.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.8 sec
Maximum speed 190 km/h
118.06 mph
Emission standard Euro 6
Weight-to-power ratio 12.5 kg/Hp, 80 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 202.8 Nm/tonne
Engine specs
Power 150 Hp @ 3500 rpm.
Power per litre 75 Hp/l
Torque 380 Nm @ 1750 rpm.
280.27 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code Ingenium / 204DTD
Engine displacement 1999 cm3
121.99 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 92.35 mm
3.64 in.
Compression ratio 15.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6.5 l
6.87 US qt | 5.72 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.4 l
7.82 US qt | 6.51 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1874 kg
4131.46 lbs.
Max. weight 2660 kg
5864.3 lbs.
Max load 786 kg
1732.83 lbs.
Fuel tank capacity 54 l
14.27 US gal | 11.88 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4599 mm
181.06 in.
Width with mirrors folded 2069 mm
81.46 in.
Width including mirrors 2173 mm
85.55 in.
Height 1724 mm
67.87 in.
Wheelbase 2741 mm
107.91 in.
Front track 1621 mm
63.82 in.
Rear (Back) track 1630 mm
64.17 in.
Drag coefficient (Cd) 0.36
Minimum turning circle (turning diameter) 11.86 m
38.91 ft.
Approach angle 23.4°
Departure angle 31°
Ramp-over (brakeover) angle 20°
Wading depth 600 mm
23.62 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 9 gears, automatic transmission
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs, 325 mm
Rear brakes Disc, 300 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
