Specifications: Land Rover Range Rover IV 3.0 SD V6 (340 Hp) AWD Automatic Hybrid 2014, 2015, 2016, 2017

2013 Land Rover Range Rover IV - Photo 1

Land Rover Range Rover IV 3.0 SD V6 (340 Hp) AWD Automatic Hybrid – Full specifications
General information
Brand Land Rover
Model Range Rover
Generation Range Rover IV
Modification (Engine) 3.0 SD V6 (340 Hp) AWD Automatic Hybrid
Start of production 2014 year
End of production 2017 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.7 l/100 km
35.1 US mpg
42.2 UK mpg
14.9 km/l
Fuel consumption (economy) – extra urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – combined 6.4 l/100 km
36.8 US mpg
44.1 UK mpg
15.6 km/l
CO2 emissions 169 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 6.9 sec
Acceleration 0 – 62 mph 6.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.6 sec
Maximum speed 218 km/h
135.46 mph
Emission standard Euro 5
Weight-to-power ratio 7 kg/Hp, 142 Hp/tonne
Weight-to-torque ratio 3.4 kg/Nm, 292.4 Nm/tonne
Electric cars and hybrids specs
Electric motor 1
Electric motor power 48 Hp
Electric motor Torque 170 Nm

125.39 lb.-ft.
System power 340 Hp @ 4000 rpm.
System torque 700 Nm @ 1500-3000 rpm.
516.29 lb.-ft. @ 1500-3000 rpm.
Internal combustion engine specs
Power 292 Hp
Power per litre 97.6 Hp/l
Torque 600 Nm
442.54 lb.-ft.
Engine layout Front, Longitudinal
Engine Model/Code 306DT
Engine displacement 2993 cm3
182.64 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.1:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6 l
6.34 US qt | 5.28 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.84 l
12.51 US qt | 10.42 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 2394 kg
5277.87 lbs.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 4999 mm
196.81 in.
Width 1983 mm
78.07 in.
Width with mirrors folded 2220 mm
87.4 in.
Height 1835 mm
72.24 in.
Wheelbase 2922 mm
115.04 in.
Drag coefficient (Cd) 0.36
Minimum turning circle (turning diameter) 12.7 m
41.67 ft.
Approach angle 34.7°
Departure angle 29.6°
Ramp-over (brakeover) angle 27.3°
Wading depth 900 mm
35.43 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission
Front suspension Air suspension
Rear suspension Air suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
