Specifications: Land Rover Range Rover IV (facelift 2017) 3.0 SDV6 (249 Hp) AWD Automatic 2018, 2019, 2020

2017 Land Rover Range Rover IV (facelift 2017) - Photo 1

Land Rover Range Rover IV (facelift 2017) 3.0 SDV6 (249 Hp) AWD Automatic – Full specifications
General information
Brand Land Rover
Model Range Rover
Generation Range Rover IV (facelift 2017)
Modification (Engine) 3.0 SDV6 (249 Hp) AWD Automatic
Start of production August, 2018 year
End of production July, 2020 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – combined 7.6 l/100 km
30.9 US mpg
37.2 UK mpg
13.2 km/l
CO2 emissions 199 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8 sec
Acceleration 0 – 62 mph 8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.6 sec
Maximum speed 209 km/h
129.87 mph
Weight-to-power ratio 9 kg/Hp, 110.5 Hp/tonne
Weight-to-torque ratio 3.8 kg/Nm, 266.3 Nm/tonne
Engine specs
Power 249 Hp @ 3500-4250 rpm.
Power per litre 83.2 Hp/l
Torque 600 Nm @ 1500-2250 rpm.
442.54 lb.-ft. @ 1500-2250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 306DT
Engine displacement 2993 cm3
182.64 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6 l
6.34 US qt | 5.28 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.93 l
9.44 US qt | 7.86 UK qt

Space, Volume and weights
Kerb Weight 2253 kg
4967.01 lbs.
Max. weight 3130 kg
6900.47 lbs.
Max load 877 kg
1933.45 lbs.
Fuel tank capacity 86 l
22.72 US gal | 18.92 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 3500 kg
7716.18 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 150 kg
330.69 lbs.
Dimensions
Length 5000 mm
196.85 in.
Width with mirrors folded 2073 mm
81.61 in.
Width including mirrors 2220 mm
87.4 in.
Height 1869 mm
73.58 in.
Wheelbase 2922 mm
115.04 in.
Front track 1693 mm
66.65 in.
Rear (Back) track 1685 mm
66.34 in.
Ride height (ground clearance) 221-297 mm
8.7 – 11.69 in.
Minimum turning circle (turning diameter) 12.7 m
41.67 ft.
Approach angle 25.5-29.7°
Departure angle 24.5-27.6°
Ramp-over (brakeover) angle 21.5-28.2°
Wading depth 900 mm
35.43 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission
Front brakes Disc, 349 mm
Rear brakes Disc, 325 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
