Specifications: Lexus NX II (AZ20) 350h (244 Hp) Hybrid AWD e-CVT 2021, 2022, 2023, 2024, 2025

2022 Lexus NX II (AZ20) - Photo 1

Lexus NX II (AZ20) 350h (244 Hp) Hybrid AWD e-CVT – Full specifications
General information
Brand Lexus
Model NX
Generation NX II (AZ20)
Modification (Engine) 350h (244 Hp) Hybrid AWD e-CVT
Start of production September, 2021 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type SUV, Crossover
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 5.9-6.4 l/100 km
39.9 – 36.8 US mpg
47.9 – 44.1 UK mpg
16.9 – 15.6 km/l
CO2 emissions (WLTP) 133-146 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.7 sec
Acceleration 0 – 62 mph 7.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.3 sec
Maximum speed 200 km/h, Electronically limited
124.27 mph
Emission standard Euro 6d
Weight-to-power ratio 7.3 kg/Hp, 136.3 Hp/tonne
Weight-to-torque ratio 7.5 kg/Nm, 133.5 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 1.6 kWh
Battery voltage 259 V
Battery technology Lithium-ion (Li-Ion)
Battery location Under the rear seats
Electric motor 1
Electric motor power 182 Hp
Electric motor Torque 270 Nm

199.14 lb.-ft.
Electric motor location Integrated into the transmission
Electric motor type Synchronous
Electric motor 2
Electric motor power 54 Hp
Electric motor Torque 121 Nm

89.25 lb.-ft.
Electric motor location Rear axle, Transverse
Electric motor type Synchronous
System power 244 Hp
Internal combustion engine specs
Power 190 Hp @ 6000 rpm.
Power per litre 76.4 Hp/l
Torque 239 Nm @ 4300-4500 rpm.
176.28 lb.-ft. @ 4300-4500 rpm.
Engine layout Front, Transverse
Engine Model/Code A25A-FXS
Engine displacement 2487 cm3
151.77 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 87.5 mm
3.44 in.
Piston Stroke 103.4 mm
4.07 in.
Compression ratio 14:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.2 l
6.55 US qt | 5.46 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1790-1870 kg
3946.27 – 4122.64 lbs.
Max. weight 2380 kg
5247 lbs.
Max load 510-590 kg
1124.36 – 1300.73 lbs.
Trunk (boot) space – minimum 545 l
19.25 cu. ft.
Trunk (boot) space – maximum 1436 l
50.71 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Dimensions
Length 4660 mm
183.46 in.
Width 1865 mm
73.43 in.
Height 1660-1670 mm
65.35 – 65.75 in.
Wheelbase 2690 mm
105.91 in.
Front track 1605 mm
63.19 in.
Rear (Back) track 1625 mm
63.98 in.
Front overhang 1007 mm
39.65 in.
Rear overhang 963 mm
37.91 in.
Ride height (ground clearance) 185-195 mm
7.28 – 7.68 in.
Drag coefficient (Cd) 0.34-0.35
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Approach angle 16°
Departure angle 25°
Drivetrain, brakes and suspension specs
Drivetrain Architecture An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent type McPherson
Rear suspension Double wishbone
Front brakes Ventilated discs, 328×34 mm
Rear brakes Ventilated discs, 317×18 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/60 R18; 235/50 R20
Wheel rims size 7.5J x 18; 7.5J x 20
