Specifications: Lexus RX II 400h (272 Hp) Hybrid AWD e-CVT 2004, 2005, 2006, 2007, 2008, 2009

2004 Lexus RX II - Photo 1

Lexus RX II 400h (272 Hp) Hybrid AWD e-CVT – Full specifications
General information
Brand Lexus
Model RX
Generation RX II
Modification (Engine) 400h (272 Hp) Hybrid AWD e-CVT
Start of production 2004 year
End of production 2009 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.1 l/100 km
25.8 US mpg
31 UK mpg
11 km/l
Fuel consumption (economy) – extra urban 7.6 l/100 km
30.9 US mpg
37.2 UK mpg
13.2 km/l
Fuel consumption (economy) – combined 8.1 l/100 km
29 US mpg
34.9 UK mpg
12.3 km/l
CO2 emissions 192 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.6 sec
Acceleration 0 – 62 mph 7.6 sec
Acceleration 0 – 60 mph 7.3 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 4
Weight-to-power ratio 7.4 kg/Hp, 136 Hp/tonne
Weight-to-torque ratio 6.9 kg/Nm, 144 Nm/tonne
Electric cars and hybrids specs
Battery voltage 288 V
Battery technology Nickel-metal hydride (NiMH)
Battery weight 69 kg
152.12 lbs.
Battery location Under the rear seats
Electric motor 1
Electric motor power 167 Hp @ 4500 rpm.
Electric motor Torque 333 Nm @ 1500 rpm.

245.61 lb.-ft. @ 1500 rpm.
Electric motor location Rear axle, Transverse
Electric motor 2
Electric motor power 68 Hp @ 4600 rpm.
Electric motor Torque 130 Nm

95.88 lb.-ft.
Electric motor location Integrated into the transmission
System power 272 Hp
Internal combustion engine specs
Power 211 Hp @ 5600 rpm.
Power per litre 63.7 Hp/l
Torque 288 Nm @ 4400 rpm.
212.42 lb.-ft. @ 4400 rpm.
Engine layout Front, Transverse
Engine Model/Code 3MZ-FE
Engine displacement 3311 cm3
202.05 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 92 mm
3.62 in.
Piston Stroke 83 mm
3.27 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, VVT-i
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9.5 l
10.04 US qt | 8.36 UK qt

Space, Volume and weights
Kerb Weight 2000-2040 kg
4409.25 – 4497.43 lbs.
Max. weight 2505 kg
5522.58 lbs.
Max load 465-505 kg
1025.15 – 1113.33 lbs.
Trunk (boot) space – minimum 439 l
15.5 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 700 kg
1543.24 lbs.
Dimensions
Length 4760 mm
187.4 in.
Width 1845 mm
72.64 in.
Height 1680 mm
66.14 in.
Wheelbase 2720 mm
107.09 in.
Front track 1580 mm
62.2 in.
Rear (Back) track 1570 mm
61.81 in.
Ride height (ground clearance) 180 mm
7.09 in.
Minimum turning circle (turning diameter) 12.2 m
40.03 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture An Internal combustion engine (ICE) drives the front wheels, one electric motor drives the front wheels, one electric motor drives the rear wheels. There is an ability for running in full electric or mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox automatic transmission e-CVT
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent coil spring, Transverse stabilizer
Front brakes Ventilated discs, 320.04 mm
Rear brakes Disc, 287.02 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/55 R18
Wheel rims size 7J x 18
