Specifications: Lexus RX III (facelift 2012) 350 V6 (270 Hp) ECT-i 2012, 2013, 2014, 2015

2012 Lexus RX III (facelift 2012) - Photo 1

Lexus RX III (facelift 2012) 350 V6 (270 Hp) ECT-i – Full specifications
General information
Brand Lexus
Model RX
Generation RX III (facelift 2012)
Modification (Engine) 350 V6 (270 Hp) ECT-i
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban (EPA) 13.1 l/100 km
18 US mpg
21.6 UK mpg
7.6 km/l
Fuel consumption (economy) – extra urban (EPA) 9.4 l/100 km
25 US mpg
30.1 UK mpg
10.6 km/l
Fuel consumption (economy) – combined (EPA) 11.2 l/100 km
21 US mpg
25.2 UK mpg
8.9 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 60 mph 7.7 sec
Maximum speed 180 km/h, Electronically limited
111.85 mph
Emission standard ULEV II
Weight-to-power ratio 7 kg/Hp, 142.5 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 177.3 Nm/tonne
Engine specs
Power 270 Hp @ 6200 rpm.
Power per litre 78.1 Hp/l
Torque 336 Nm @ 4700 rpm.
247.82 lb.-ft. @ 4700 rpm.
Maximum engine speed 6400 rpm.
Engine layout Front, Transverse
Engine Model/Code 2GR-FE
Engine displacement 3456 cm3
210.9 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 94 mm
3.7 in.
Piston Stroke 83 mm
3.27 in.
Compression ratio 10.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC, Dual VVT-i
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.6 l
9.09 US qt | 7.57 UK qt

Space, Volume and weights
Kerb Weight 1895-1969 kg
4177.76 – 4340.9 lbs.
Max. weight 2522 kg
5560.06 lbs.
Max load 553-627 kg
1219.16 – 1382.3 lbs.
Trunk (boot) space – minimum 446 l
15.75 cu. ft.
Trunk (boot) space – maximum 1570 l
55.44 cu. ft.
Fuel tank capacity 72.5 l
19.15 US gal | 15.95 UK gal
Permitted trailer load with brakes (12%) 1588 kg
3500.94 lbs.
Dimensions
Length 4770 mm
187.8 in.
Width 1885 mm
74.21 in.
Height 1720 mm
67.72 in.
Wheelbase 2740 mm
107.87 in.
Front track 1630 mm
64.17 in.
Rear (Back) track 1625 mm
63.98 in.
Front overhang 1000 mm
39.37 in.
Rear overhang 1030 mm
40.55 in.
Ride height (ground clearance) 185 mm
7.28 in.
Drag coefficient (Cd) 0.33
Minimum turning circle (turning diameter) 12.2 m
40.03 ft.
Approach angle 28.6°
Departure angle 24.9°
Ramp-over (brakeover) angle 14.4°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission ECT-i
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Double wishbone, Transverse stabilizer, Coil spring
Front brakes Ventilated discs, 328 mm
Rear brakes Disc, 310 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/60 R18; 235/55 VR19
Wheel rims size 7.5J x 18; 7.5J x 19
