Specifications: Nissan Cube (Z12) 1.5 (109 Hp) 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019

Nissan Cube (Z12) 1.5 (109 Hp) – Full specifications
General information
Brand	Nissan
Model	Cube
Generation	Cube (Z12)
Modification (Engine)	1.5 (109 Hp)
Start of production	2008 year
End of production	2019 year
Powertrain Architecture	Internal Combustion engine
Body type	Station wagon (estate)
Seats	5
Doors	5
Performance specs
Fuel Type	Petrol (Gasoline)
Weight-to-power ratio	10.7 kg/Hp, 93.2 Hp/tonne
Weight-to-torque ratio	7.9 kg/Nm, 126.5 Nm/tonne
Engine specs
Power	109 Hp @ 6000 rpm.
Power per litre	72.8 Hp/l
Torque	148 Nm @ 4400 rpm. 109.16 lb.-ft. @ 4400 rpm.
Engine layout	Front, Transverse
Engine Model/Code	HR15DE
Engine displacement	1498 cm³ 91.41 cu. in.
Number of cylinders	4
Engine configuration	Inline
Cylinder Bore	73.6 mm 2.9 in.
Piston Stroke	88 mm 3.46 in.
Compression ratio	9.9:1
Number of valves per cylinder	4
Fuel injection system	Multi-port manifold injection
Engine aspiration	Naturally aspirated engine
Valvetrain	DOHC
Engine oil capacity	3 l 3.17 US qt \| 2.64 UK qt
Engine oil specification	Log in to see.
Coolant	6.6 l 6.97 US qt \| 5.81 UK qt

Space, Volume and weights
Kerb Weight	1170 kg 2579.41 lbs.
Fuel tank capacity	45 l 11.89 US gal \| 9.9 UK gal
Dimensions
Length	3890 mm 153.15 in.
Width	1695 mm 66.73 in.
Height	1650 mm 64.96 in.
Wheelbase	2530 mm 99.61 in.
Front track	1480 mm 58.27 in.
Rear (Back) track	1485 mm 58.46 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel	Front wheel drive
Front brakes	Ventilated discs
Rear brakes	Drum
Tires size	175/65 R15
