Specifications: Nissan NV200 Evalia 1.5 dCi (90 Hp) 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019

2010 Nissan NV200 Evalia - Photo 1

Nissan NV200 Evalia 1.5 dCi (90 Hp) – Full specifications
General information
Brand Nissan
Model NV200
Generation NV200 Evalia
Modification (Engine) 1.5 dCi (90 Hp)
Start of production 2010 year
End of production 2019 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – extra urban 4.8 l/100 km
49 US mpg
58.85 UK mpg
20.83 km/l
Fuel consumption (economy) – combined 5.1 l/100 km
46.12 US mpg
55.39 UK mpg
19.61 km/l
CO2 emissions 133 g/km
Fuel Type Diesel
Maximum speed 158 km/h
98.18 mph
Emission standard Euro 6
Weight-to-power ratio 15.3 kg/Hp, 65.4 Hp/tonne
Weight-to-torque ratio 6.9 kg/Nm, 145.3 Nm/tonne
Engine specs
Power 90 Hp @ 4000 rpm.
Power per litre 61.6 Hp/l
Torque 200 Nm @ 1750 rpm.
147.51 lb.-ft. @ 1750 rpm.
Engine layout Front, Transverse
Engine Model/Code K9K 892
Engine displacement 1461 cm3
89.16 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 76 mm
2.99 in.
Piston Stroke 80.5 mm
3.17 in.
Compression ratio 15.2:1
Number of valves per cylinder 2
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1376-1423 kg
3033.56 – 3137.18 lbs.
Max. weight 2060 kg
4541.52 lbs.
Max load 637-684 kg
1404.34 – 1507.96 lbs.
Trunk (boot) space – minimum 2300 l
81.22 cu. ft.
Trunk (boot) space – maximum 3100 l
109.48 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 1100 kg
2425.08 lbs.
Permitted trailer load without brakes 640 kg
1410.96 lbs.
Permitted towbar download 44 kg
97 lbs.
Dimensions
Length 4400 mm
173.23 in.
Width 1695 mm
66.73 in.
Width including mirrors 2011 mm
79.17 in.
Height 1860 mm
73.23 in.
Wheelbase 2725 mm
107.28 in.
Front track 1490 mm
58.66 in.
Rear (Back) track 1510 mm
59.45 in.
Minimum turning circle (turning diameter) 10.60 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Leaf spring
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 175/70 R14C
Wheel rims size 5.5JJ x 14
