| General information | |
|---|---|
| Brand | Nissan |
| Model | Patrol |
| Generation | Patrol VII (Y63) |
| Modification (Engine) | NISMO 3.5 V6 (495 Hp) 4WD Automatic |
| Start of production | June, 2025 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | SUV |
| Seats | 8 |
| Doors | 5 |
| Performance specs | |
| Fuel Type | Petrol (Gasoline) |
| Weight-to-power ratio | 5.7 kg/Hp, 175.7 Hp/tonne |
| Weight-to-torque ratio | 4 kg/Nm, 248.5 Nm/tonne |
| Engine specs | |
| Power | 495 Hp @ 5600 rpm. |
| Power per litre | 141.8 Hp/l |
| Torque | 700 Nm @ 3600 rpm. 516.29 lb.-ft. @ 3600 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | VR35DDTT |
| Engine displacement | 3492 cm3 213.09 cu. in. |
| Number of cylinders | 6 |
| Engine configuration | V-engine |
| Cylinder Bore | 86 mm 3.39 in. |
| Piston Stroke | 100.2 mm 3.94 in. |
| Compression ratio | 10.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Twin-Turbo, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 5.3 l 5.6 US qt | 4.66 UK qt |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 2817 kg 6210.42 lbs. |
| Dimensions | |
| Length | 5295 mm 208.46 in. |
| Width | 2070 mm 81.5 in. |
| Height | 1945 mm 76.57 in. |
| Wheelbase | 3075 mm 121.06 in. |
| Front track | 1730 mm 68.11 in. |
| Rear (Back) track | 1730 mm 68.11 in. |
| Ride height (ground clearance) | 195 mm 7.68 in. |
| Approach angle | 23° |
| Departure angle | 25.5° |
| Ramp-over (brakeover) angle | 26° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle. |
| Drive wheel | All wheel drive (4×4) |
| Number of gears and type of gearbox | 9 gears, automatic transmission |
| Front suspension | Double wishbone, Air suspension |
| Rear suspension | Double wishbone, Air suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 275/50 R22 |
| Wheel rims size | 22 |
