Specifications: Nissan Serena (C23M) 1.6 16V (97 Hp) 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000

1992 Nissan Serena (C23M) - Photo 1

Nissan Serena (C23M) 1.6 16V (97 Hp) – Full specifications
General information
Brand Nissan
Model Serena
Generation Serena (C23M)
Modification (Engine) 1.6 16V (97 Hp)
Start of production 1993 year
End of production 2000 year
Powertrain Architecture Internal Combustion engine
Body type Minivan
Seats 8
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.3 l/100 km
20.82 US mpg
25 UK mpg
8.85 km/l
Fuel consumption (economy) – extra urban 7.8 l/100 km
30.16 US mpg
36.22 UK mpg
12.82 km/l
Fuel consumption (economy) – combined 10.7 l/100 km
21.98 US mpg
26.4 UK mpg
9.35 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 17.9 sec
Acceleration 0 – 62 mph 17.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 17 sec
Maximum speed 150 km/h
93.21 mph
Weight-to-power ratio 14.4 kg/Hp, 69.5 Hp/tonne
Weight-to-torque ratio 10.6 kg/Nm, 94.6 Nm/tonne
Engine specs
Power 97 Hp @ 5600 rpm.
Power per litre 60.7 Hp/l
Torque 132 Nm @ 3600 rpm.
97.36 lb.-ft. @ 3600 rpm.
Engine layout Middle, Longitudinal
Engine displacement 1597 cm3
97.45 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 76 mm
2.99 in.
Piston Stroke 88 mm
3.46 in.
Compression ratio 9.8:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC

Space, Volume and weights
Kerb Weight 1396 kg
3077.65 lbs.
Max. weight 2100 kg
4629.71 lbs.
Max load 704 kg
1552.05 lbs.
Trunk (boot) space – minimum 350 l
12.36 cu. ft.
Trunk (boot) space – maximum 620 l
21.9 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4315 mm
169.88 in.
Width 1710 mm
67.32 in.
Height 1840 mm
72.44 in.
Wheelbase 2735 mm
107.68 in.
Front track 1490 mm
58.66 in.
Rear (Back) track 1460 mm
57.48 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Coil spring
Rear suspension Leaf spring
Front brakes Ventilated discs
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/70 R14
Wheel rims size 14
