Specifications: Oldsmobile Cutlass Supreme Holiday Sedan 5.4 V8 (320 Hp) Manual 3-speed 1966, 1967

Oldsmobile Cutlass Supreme Holiday Sedan 5.4 V8 (320 Hp) Manual 3-speed – Full specifications
General information
Brand	Oldsmobile
Model	Cutlass
Generation	Cutlass Supreme Holiday Sedan
Modification (Engine)	5.4 V8 (320 Hp) Manual 3-speed
Start of production	1966 year
End of production	1967 year
Powertrain Architecture	Internal Combustion engine
Body type	Sedan
Seats	5
Doors	4
Performance specs
Fuel Type	Petrol (Gasoline)
Weight-to-power ratio	4.9 kg/Hp, 206.2 Hp/tonne
Weight-to-torque ratio	3.2 kg/Nm, 314.4 Nm/tonne
Engine specs
Power	320 Hp
Power per litre	59.2 Hp/l
Torque	488 Nm 359.93 lb.-ft.
Engine layout	Front, Longitudinal
Engine displacement	5408 cm³ 330.02 cu. in.
Number of cylinders	8
Engine configuration	V-engine
Number of valves per cylinder	2
Fuel injection system	Carburettor
Engine aspiration	Naturally aspirated engine
Valvetrain	OHV
Engine oil capacity	4.7 l 4.97 US qt \| 4.14 UK qt
Coolant	15.6 l 16.48 US qt \| 13.73 UK qt

Space, Volume and weights
Kerb Weight	1552 kg 3421.57 lbs.
Fuel tank capacity	76 l 20.08 US gal \| 16.72 UK gal
Dimensions
Length	5187 mm 204.21 in.
Width	1930 mm 75.98 in.
Height	1382 mm 54.41 in.
Wheelbase	2921 mm 115 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture	The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel	Rear wheel drive
Number of gears and type of gearbox	3 gears, manual transmission
Front brakes	Drum
Rear brakes	Drum
Tires size	205/75 SR14; 225/70 SR14
Wheel rims size	6J x 14 ET0; 7J x 14 ET0
