Specifications: Opel Ascona C CC 1.6 D (54 Hp) 1982, 1983, 1984, 1985, 1986, 1987, 1988

1982 Opel Ascona C CC - Photo 1

Opel Ascona C CC 1.6 D (54 Hp) – Full specifications
General information
Brand Opel
Model Ascona
Generation Ascona C CC
Modification (Engine) 1.6 D (54 Hp)
Start of production 1982 year
End of production 1988 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel Type Diesel
Acceleration 0 – 100 km/h 20 sec
Acceleration 0 – 62 mph 20 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 19 sec
Maximum speed 141 km/h
87.61 mph
Weight-to-power ratio 19.3 kg/Hp, 51.9 Hp/tonne
Weight-to-torque ratio 10.8 kg/Nm, 92.3 Nm/tonne
Engine specs
Power 54 Hp @ 4600 rpm.
Power per litre 33.8 Hp/l
Torque 96 Nm @ 2400 rpm.
70.81 lb.-ft. @ 2400 rpm.
Engine Model/Code 16D
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 80 mm
3.15 in.
Piston Stroke 79.5 mm
3.13 in.
Compression ratio 23:1
Number of valves per cylinder 2
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.5 l
7.93 US qt | 6.6 UK qt

Space, Volume and weights
Kerb Weight 1040 kg
2292.81 lbs.
Max. weight 1550 kg
3417.17 lbs.
Max load 510 kg
1124.36 lbs.
Trunk (boot) space – minimum 445 l
15.72 cu. ft.
Trunk (boot) space – maximum 1215 l
42.91 cu. ft.
Fuel tank capacity 61 l
16.11 US gal | 13.42 UK gal
Permitted trailer load without brakes 700 kg
1543.24 lbs.
Dimensions
Length 4264 mm
167.87 in.
Width 1668 mm
65.67 in.
Height 1385 mm
54.53 in.
Wheelbase 2574 mm
101.34 in.
Front track 1406 mm
55.35 in.
Rear (Back) track 1406 mm
55.35 in.
Ride height (ground clearance) 145 mm
5.71 in.
Drag coefficient (Cd) 0.38
Minimum turning circle (turning diameter) 10.95 m
35.93 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 4 gears, manual transmission
Front brakes Disc
Rear brakes Drum
